广濑/HRS连接器 DF16(2.0)-60DP-0.5V(86) 基板对基板连接器
| 价 格： | 面议 | |
| 接口类型： | ----- | |
| 接触件材质： | ----- | |
| 针数： | ----- | |
| 种类： | 板对板 | |
| 加工定制： | 否 | |
| 形状： | 条形 | |
| 线长： | -----（mm） | |
| 应用范围： | PCB | |
| 型号： | DF16(2.0)-60DP-0.5V(86) | |
| 工作频率： | 低频 | |
| 特性： | 防潮 | |
| 绝缘体材质： | ----- | |
| 品牌： | Hirose/广濑 | |
| 支持卡数： | 单卡 | |
| 芯数： | ----- | |
| 读卡类型： | CF | |
| 制作工艺： | 冷压 |
Hirose/广濑 HRS接插件 基板对基板连接器 连接器DF16系列 叠层高度2～2.5mm的二件式连接器Features ● In addition to 0.5mm pitch miniaturization, the board-to-board stacking height of 2mm and 2.5mm are provided. ● The bellows female contact has sufficient spring characteristic despite the low profile, and achieves high contact reliability. ● The click feeling is considered to facilitate insertion check when the connector is mated. ● The connector has the vacuum area, which enables the automatic mounting by the embossed tape packaging. ● The product including the metal holddown to prevent solder peeling is prepared, considering the mounting on FPC.
| Characteristic | Specifications |
| No. of Positions | 14, 16, 20, 30, 40, 50, 60, 80 |
| Current Rating(Amps)(Max.) | 0.3 |
| PCB Mount Type | SMT |
| Contact Mating Area Plating | Gold |
| Terminal Pitch (mm) | 0.5 |
| Contact Spacing (mm) | 0.5 |
| Stack Height (mm) | 2, 2.5 |
| Operating Temperature Range (degrees C) | -35 to 85 |
| Connector Type | Board mounting |
| Contact Gender | Female, Male |
dzsc/19/2778/19277868.jpg
dzsc/19/2778/19277868.jpg
dzsc/19/2778/19277868.jpg
同系列型号有：
- 所属城市：上海 上海市
- [联系时请说明来自维库仪器仪表网]
- 联系人： 徐清强
- 电话：021-54432312
- 传真：021-54432312
- 手机：
- QQ ：
广濑/HRS连接器 DF16B(2.5)-20DP-0.5V(86) 基板对基板连接器
信息内容：Hirose/广濑 HRS接插件 基板对基板连接器 连接器DF16系列叠层高度2～2.5mm的二件式连接器Features●In addition to 0.5mm pitch miniaturization, the board-to-board stacking height of 2mm and 2.5mm are provided.●The bellows female contact has sufficient spring characteristic despite the low profile, and achieves high contact reliability.●The click feeling is considered to facilitate insertion check when the connector is mated.●The connector has the vacuum area, which enables the automatic mounting by the embossed tape packaging.●The product including the metal holddown to prevent solder peeling is prepared, considering the mounting on FPC. CharacteristicSpecificationsNo. of Positions14, 16, 20, 30, 40, 50, 60, 80Current Rating(Amps)(Max.)0.3PCB Mount TypeSMTContact Mating Area PlatingGoldTerminal Pitch (mm)0.5Contact Spacing (mm)0.5Stack Height (mm)2, 2.5Operating Temperature Range (degrees C)-35 to 85Connector TypeBoard mountingContact GenderFemale, Male dzsc/19/2779/19277983.jpgdzsc/...
OMRON欧姆龙DIN连接器XC5B-322P-1140/322P-1131 Fine F...
信息内容：XC5 DIN连接器（Fine Fit、W针型） 国际规格的DIN连接器无焊接连接（通称压装）系列 欧姆龙连接器XC5型特点如下● 符合DIN规格，轻松实现背板系统。● W形状，实现少扭曲、少歪倒，可进行高可靠性连接。● 是一种对印刷基板通孔损害较小的形状。● 作为背板连接用连接器，可使用欧姆龙XC6系列。● 插座采用高可靠性的双触点型（2点接触）。● 备用专用压入夹具。 dzsc/19/2780/19278021.jpgdzsc/19/2780/19278021.jpgdzsc/19/2780/19278021.jpgdzsc/19/2780/19278021.jpgdzsc/19/2780/19278021.jpgdzsc/19/2780/19278021.jpgXC5B-322P-1140 XC5B-322P-1131 XC5B-322P-1132XC5B-642P-1140 XC5B-642P-1131 XC5B-642P-1132XC5B-012P-1140 — —XC5E-322P-1140 XC5E-322P-1131 XC5E-322P-1132XC5E-642P-1140 XC5E-642P-1131 XC5E-642P-1132XC5E-012P-1140 — —XC5D-482P-1140 XC5D-482P-1131 XC5D-482P-1132XC5D-642P-1140 XC5D-642P-1131 XC5D-642P-1132XC5D-962P-1140 XC5D-962P-1131 XC5D-962P-1132XC5G-482P-1140 XC5G-48...
