Hirose/广濑 HRS 连接器 HRMM-101(40) 同轴连接器
| 价 格： | 面议 | |
| 接口类型： | ------ | |
| 接触件材质： | ----- | |
| 针数： | ----- | |
| 种类： | 射频同轴(RF) | |
| 加工定制： | 否 | |
| 形状： | 圆形 | |
| 线长： | -----（mm） | |
| 应用范围： | 通讯 | |
| 型号： | HRMM-101(40) | |
| 工作频率： | 低频 | |
| 特性： | 防潮 | |
| 绝缘体材质： | ----- | |
| 品牌： | Hirose/广濑 | |
| 支持卡数： | 单卡 | |
| 芯数： | ----- | |
| 读卡类型： | CF | |
| 制作工艺： | 冷压 |
Hirose/广濑 HRS连接器 同轴连接器 连接器HRMM系列
SSMA型螺钉联接型标准同轴连接器
| Features | |
| ● | SSMA connectors meeting MIL and IEC standards. |
| ● | Stainless steel shell ensuring high durability. |
| ● | Reduced in size to about 80% of HRM (SMA type) connectors. |
| ● | V.S.W.R.: 1.2 max., from DC to 12.4GHz. Models using flexible cable: 1.2 max., from DC to 1GHz |
| Characteristic | Specifications |
| PCB Mount Type | Through-hole |
| Generic Name | SSMA |
| Contact Mating Area Plating | Gold |
| Impedance (ohm) | 50 |
| Frequency Range (GHz) | 0 to 20 |
| Operating Temperature Range (degrees C) | -55, -30 to 60, 85 |
| Applicable Cable | 0.085 inch semi rigid, 1.5D-2V, 1.5D-2V, 1.5D-HQEV, 1.5D-QEV, 1.5D-Q.SUPER, RG-196A/U, RG-405/U, 0.085 inch semi rigid |
| Termination Style | Soldering |
| Connector Type | Adapter/Board mounting/Cable/Panel |
| Contact Gender | Female, Male |
| Mating/Unmating Cycles | 500, 1000 |
| Remarks | Extraction tool, Conversion adaptor (BWA series) |
| VSWR (Max) | 1.07, 1.1, 1.2, 1.3, 1.35 |
dzsc/19/2422/19242247.jpg
dzsc/19/2422/19242247.jpg
dzsc/19/2422/19242247.jpg
