led灯珠 3MM雾状蓝光
| 价 格： | 面议 | |
| 颜色： | 蓝色 | |
| 型号/规格： | 直插 | |
| 品牌/商标： | MEI9 | |
| 种类： | 发光二极管 | |
| 加工定制： | 是 | |
| 形状： | 方片 |
SPECIFICATION
ABSOLUTE MAXIMUM RATING (Ta=25℃)
Item | Symbol | Rating | Unit |
Power Dissipation | PD | 72 | mW |
Forward Current | IF | 20 | mA |
Peak Forward Current (1/10 Duty Cycle, 0.1 ms Pulse Width) | IFP | 100 | mA |
Reverse Voltage | VR | 5 | V |
Operating Temperature | Topr | -40~ 80 | ℃ |
Storage Temperature | Tstg | -40~ 80 | ℃ |
ELECTRICAL/OPTICAL CHARACTERISTICS RATING (Ta=25℃)
Item | Symbol | Test Condition | Rating | Unit | ||
Min. | Typ. | Max. | ||||
Forward Voltage | VF | IF=20mA | 2.8 | --- | 3.4 | V |
Reverse Current | IR | VR=5V | --- | --- | 10 | μA |
Luminous Intensity | IV | IF=20mA | 300 | --- | 800 | mcd |
Dominant Wave Length | λd | IF=20mA | 456 | --- | 466 | nm |
Viewing Angle2θ1/2 | 2θ1/2 | IF=20mA | 35° | deg. | ||
PACKAGE DIMENSION
|
