供应3M 558, 汽车端子,汽车连接器
| 价 格： | 面议 | |
| 加工定制： | 否 | |
| 品牌/商标： | 3M | |
| 型号/规格： | 3M 558 | |
| 应用范围： | 汽车 | |
| 种类： | 端子(terminal) | |
| 接口类型： | IDC | |
| 支持卡数： | 二合一 | |
| 读卡类型： | Micro | |
| 形状： | 矩形 | |
| 制作工艺： | 冷压 | |
| 特性： | 防潮 | |
| 接触件材质： | 金属 | |
| 绝缘体材质： | PVC | |
| 芯数： | 二芯 |
现货供应3M 558夹线端子 30000PCS
16~22AWG
UL /CSA 认证.
| 3M™ Scotchlok™ 558 Electrical IDC, Run and Tap, Flame Retardant |
 [click to enlarge] |  | Electrically connects a (tap) wire end to a through (run) wire and insulates the connection. Designed for control circuit wiring, fixture wiring, appliance wiring, signal and PA systems, automotive/boat/RV wiring. It has an AWG range 22-16 (0,5-1,5).
深圳市浩然达科技有限公司
公司信息未核实
公司相关产品
汽车连接器信息内容：Scotchlok™ 558 ElectricalConnectorsApplicationUse Part No. 558 to electrically connect a (tap) wireend to a through (run) wire and insulate theconnection.Wire Range22-16 AWG Solid or stranded, tinned or untinned(.5-1.5 mm2 str.) copper conductors. For use withcommon thermoplastic insulated wires such as: T, TF,TFF, TFN, TFFN, AWM, TEW, SAE-GPT with amaximum insulation diameter of .120 inches (3,0 mm).Maximum recommended current for general purposeapplications: 22 AWG - 3 AMPS, 20 AWG - 4 AMPS,18 AWG - 7 AMPS, 16 AWG - 10 AMPS.ConstructionU-contact - Tin plated brass, .02 in. (.5 mm) thickInsulator - Flame retardant polypropylene,Color - red 相关产品 |
