0/1-10V LED调光驱动器0/1-10V LED Dimming Driver

随着LED照明的兴起，LED照明灯光在酒店、商业中心、家庭逐渐大量应用，LED和 荧光灯在同一场合应用的机会越来越多，如果用传统比较成熟的荧光灯调光系统把LED纳入系统控制是非常方便的，但LED照明调光原理和传统的荧光灯调光原理不一样，荧光灯调光系统不能直接对LED进行调光。Along with the rise of LED illumination, LED lamps are widely used in hotel, business center, household decoration etc. there are more and more chances to use LED and fluorescent lights at the same project, if LED lamps and fluorescent lights can be controlled together by a traditional fluorescent dimming system, it will make everything more convenient, but the dimming principles of LED and traditional fluorescent lights are different, LED lights can not be dimmed by the fluorescent dimming controller directly.

我司推出的0-10V至PWM系列调光驱动器完美解决了荧光灯调光系统与LED照明兼容的问题，可以利用众多的传统照明智能调光系统控制LED灯光, 例如各种LED天花灯、LED筒灯、LED平板灯、LED灯条等等。As a fact of that, our company developed a new 0-10V to PWM dimming driver which has solved the compatible problem of fluorescent dimming system. and LED illumination, LED lamps can be controlled by many traditional intelligent dimming system.

注：恒压跟恒流的调光驱动器可以混合连接在调光系统上，方便不同电压、大功率和小功率的LED灯统一控制。NOTE：The CV Dimming Drive andCC Dimming Drive can be connected together on the same dimming system, which is convenient for controlling different LED lamps with different voltage and power.

LT-701-CC 兼容0-10V,1-10V,Reistor and the PUSH BUTTON 接入调光。LT-701-CC is compatible with the 0-10V,1-10V,Reistor and the PUSH BUTTON insert dimming.

dzsc/19/1101/19110174.jpg



产品参数Product parameter

LT-701-CC 恒流0-10V调光驱动器 CC 0-10V Dimming Driver

输入信号Input signal: 0/1-10V OR PUSH-DIM

输入电压Input voltage: DC12V～DC48V

输出电压Output voltage:DC3V~DC42V

输出电流Max load current: 恒流350/700/1050mA

驱动LED数量Driving LEDs:1～12颗大功率1W LED / 1~12 pcs LEDs

输出信号Output signal:1 CH CC PWM

调光范围Dimming Range: 0~100%

工作温度working temperature: -30℃～55℃

产品尺寸Dimension: L175×W44×H30(mm)

包装尺寸Package Size: L178×W48×H33(mm)

重量(毛重) Weight (G.W):110g

dzsc/19/1101/19110174.jpg

dzsc/19/1101/19110174.jpg

dzsc/19/1101/19110174.jpg

dzsc/19/1101/19110174.jpg

dzsc/19/1101/19110174.jpg

dzsc/19/1101/19110174.jpg

dzsc/19/1101/19110174.jpg
