概述：
   The XESD5VD923B ESD protector is designed to replace multilayer varistors (MLVs) in portable applications such as cell phones, notebook computers, and PDA’s. They feature large cross-sectional area junctions for conducting high transient currents, offer desirable electrical characteristics for board level protection, such as fast response time, lower operating voltage, lower clamping voltage and no device degradation when compared to MLVs. The XESD5VD923Bprotects sensitive semiconductor components from damage or upset due to electrostatic discharge (ESD) and other voltage induced transient events. The  is available in a SOD-923 XESD5VD923B package with working voltages of 5 volt. It gives designer the flexibility to protect one bidirectional line in applications where arrays are not practical. Additionally, it may be “sprinkled” around the board in applications where board space is  at a premium. It may be used to meet the ESD immunity requirements of IEC 61000-4-2, Level 4 (±15kV air, ±8kV contact discharge)

特点：
„  100 Watts peak pulse power (tp = 8/20μs)
„  Transient protection for data lines to
IEC 61000-4-2 (ESD) ±25kV (air), ±10kV (contact)
IEC 61000-4-4 (EFT) 40A (5/50ns)
IEC 61000-4-5 (Lightning) 24A (8/20μs)
„  Small package for use in portable electronics
„  Suitable replacement for MLV’s in ESD protection applicatio
„  Protect one I/O or power line
„  Low clamping voltage
„  Stand off voltages: 5V
„  Low leakage current
„  Solid-state silicon-avalanche technology
„  Small Body Outline Dimensions: 1.0mm×0.6mm×0.5mm
„  Equivlent to 0402 package

应用范围：
„  Cell Phone Handsets and Accessories
„  Personal Digital Assistants (PDA’s)
„  Notebooks, Desktops, and Servers
„  Portable Instrumentation
„  Cordless Phones
„  Digital Cameras
„  Peripherals
„  MP3 Players
