同轴连接器，射频连接器，F连接器，屏蔽式，F母
| 价 格： | 0.65 | |
| 品牌/商标： | EASTRON | |
| 型号/规格： | 同轴连接器，射频连接器，F连接器EF-0813 | |
| 应用范围： | PCB | |
| 种类： | 射频同轴(RF) | |
| 接口类型： | F | |
| 形状： | F | |
| 制作工艺： | MACHINED | |
| 特性： | EASTRON | |
| 工作频率： | 高频 | |
| 接触件材质： | CU |
| 75 O impedance connector features a threaded coupling. F-type connectors are | |||||
| of low price and developed for NTSC TV Antenna etc. | |||||
| Electrical | |||||
| Impedance | 75 ohm | ||||
| Frequency Range | 0-1 GHZ | ||||
| Working Voltage | 500 VRMS max. | ||||
| Dielectric Withstanding Voltag | 1500VRMS min | ||||
| VSWR | Straight | 1.5 max | |||
| Right Angle | 1.7 Max | ||||
| Contact Resistance | Center contact | 50 Milliohms Max. | |||
| Outer contact | 3 Milliohms Max | ||||
| Insulator Resistance | 5000 Megohms min | ||||
| MATERIAL | |||||
| Parts Name | MATERIAL | Finish | |||
| Body, metal Parts | Brass | Nickel or Gold plated | |||
| Center Contacts | Plug:Brass | Nickel, Gold or Silver per requirement | |||
| Jack:Beryllium copper, Phosphor Bronze or Brass | Nickel,Gold or Silver per requirement | ||||
| Insulators | Teflon, POM, PP | None | |||
| Crimp ferrules | Annealed copper | Nickel or Gold Per requirement | |||
