批发可控硅,ST原裝進口,BTA06,600C
| 价 格： | 1.55 | |
| 品牌/商标： | ST/意法 | |
| 型号/规格： | BTA06-600C | |
| 控制方式： | 双向 | |
| 极数： | 三极 | |
| 封装材料： | 塑料封装 | |
| 封装外形： | TO-220 | |
| 关断速度： | 高频(快速) | |
| 散热功能： | 带散热片 | |
| 功率特性： | 小功率 | |
| 额定正向平均电流： | 6（A） | |
| 控制极触发电流： | 5-50（mA） | |
| 稳定工作电流： | 6（A） | |
| 反向重复峰值电压： | 600（V） | |
| 正向重复峰值电压： | 600 |
dzsc/19/0844/19084449.jpg
公司中文域名：杰宝莱
公司网络实名：中国可控硅批发商 贴片可控硅
公司主页：http://jbl-sz.com
阿里巴巴网站：http://jepoler.cn.alibaba.com
http://jblchj.cn.alibaba.com
QQ：908152203
MAINFEATURES: |
| |
Symbol | Value | Unit |
IT(RMS) | 6 | A |
VDRM/VRRM | 600 and 800 | V |
IG (Q1) | 5 to 50 | mA |
DESCRIPTION
Suitable for AC switching operations, the BTA/
BTB06 series can be used as an ON/OFF function
in applications such as static relays, heating
regulation, induction motor starting circuits... or for
phase control in light dimmers, motor speed
controllers,...
The snubberless and logic level versions (BTA/
BTB...W) are specially recommended for use on
inductive loads, thanks to their high commutation
performances. By using an internal ceramic pad,
the BTA series provides voltage insulated tab
(rated at 2500V RMS) complying with UL
standards (File ref.: E81734)
ABSOLUTE MAXIMUM RATINGS
Symbol | Parameter | Value | Unit | ||
IT(RMS) | RMS on-state current (full sine wave) | TO-220AB | Tc = 110°C | 6 | A |
TO-220AB Ins. | Tc = 105°C |
| |||
ITSM | Non repetitive surge peak on-state current (full cycle, Tj initial = 25°C) | F = 50 Hz | t = 20 ms | 60 | A |
F = 60 Hz | t = 16.7 ms | 63 | |||
I²t | I²t Value for fusing | tp = 10 ms | 21 | A²s | |
dI/dt | Critical rate of rise of on-state current IG= 2 x IGT, tr £100 ns | F = 120 Hz | Tj = 125°C | 50 | A/µs |
IGM | Peak gate current | tp = 20 µs | Tj = 125°C | 4 | A |
PG(AV) | Average gate power dissipation | Tj = 125°C | 1 | W | |
TstgTj | Storage junction temperature range Operating junction temperature range | - 40 to 150 - 40 to 125 | °C | ||
