友达液晶屏 AUO 6.5寸 Color TFT-LCD PANEL G065VN01 V2
| 价 格： | 802.00 | |
| 加工定制： | 否 | |
| 品牌/商标： | AUO/友达 | |
| 型号/规格： | G065VN01 V2 | |
| 种类： | LCD液晶屏 | |
| 屏幕尺寸： | 6.5（英寸） | |
| 色彩： | G065VN01 V2 | |
| 亮度： | G065VN01 V2 | |
| 对比度： | G065VN01 V2 | |
| 分辨率： | G065VN01 V2 | |
| 像素： | G065VN01 V2 | |
| 点距： | 1（mm） | |
| 响应时间： | 1（ms） | |
| 可视角度： | 1（°） |
????>> AUO 6.5" Color TFT-LCD PANEL G065VN01 V2??<<????
Model: G065VN01 V2
Size: 6.5"
Resolution (pixel) : VGA (640 x 480)
dzsc/19/0750/19075021.jpg
Today, flat panels are everywhere. AUO is the backbone behind these changes. We provide displays for every use you can dream of : ATM, POS, Kiosk, IPC (Industrial PC), security system, lottery/gambling gaming machines, medical equipments, factory automation (FA), e-Signage, and Public Information Display (PID). Products are uniquely designed with high brightness, wide viewing angles, long lamp life and lower power consumption.
General Display
Model G065VN01 V2
Size 6.5"
Resolution (pixel) VGA (640 x 480)
Active Area 132.5 x 99.4
Pixel Pitch (mm) 0.207
Mode TN
Number of Colors 262K / 16.2M
Color Saturation (%) 55
Viewing Angle (H/V) 160 / 140
Brightness (cd/m2) 800
Contrast Ratio 600 : 1
Response Time (ms) 25
Power Consumtion (W) 3.9
Interface LVDS
Supply Voltage (v) 3.3
Light Source LED
Outline Dimension (mm) 153 x 118 x 10.9
Weight (g) 170
Production Now
Reverse Scan Replaceable LED 6/8 bit Convertible Wide Temperature
