开模定制LCD液晶屏 定制超宽温LCD液晶屏 定制超宽温液晶模块
| 价 格： | 10.00 | |
| 加工定制： | 是 | |
| 品牌/商标： | Good Display | |
| 型号/规格： | EDC190 | |
| 种类： | LCD液晶屏 | |
| 屏幕尺寸： | 2（英寸） | |
| 色彩： | LCD液晶屏 | |
| 亮度： | 可定制 | |
| 对比度： | 可选 | |
| 分辨率： | 可定制 | |
| 像素： | 可选 | |
| 点距： | 6.6x13.2（mm） | |
| 响应时间： | 9（ms） | |
| 可视角度： | +30至-40（°） |
开模定制LCD液晶屏 定制超宽温LCD液晶屏 定制超宽温液晶模块
Feature:
Product name:TN Static LCD Screen
Product Number: EDC190
Display Type:TN,Transflactive,Positive
Content: 4 Digits
Outline Dimension: 50.8x30.48x2.8mm
View Area(W×H):45.72x17.78mm
Char size(W×H):6.6x13.2mm
Viewing direction:6 O'Clock
Multplex level: Static
Back Light: LED
Connector:PIN
Operating Temp:-20-- 70
Storage Temp: -30-- 80
| Products No. | Display Content | Outline Dimension(mm) | View Aera (mm) | Digit Size (mm) | Driving Mode |
| EDC002 | 8 Digits | 63.5x20.32x2.8 | 60.7x13.46 | 5.14x10.7 | Static |
| EDC004 | 1 Digit | 50.0X33.0 | 38.9X27.9 | 34.5x19.0 | Static |
| EDC006 | 1 Digit | 76.2X55.88 | 65.0x50.8 | 56.18x36.63 | Static |
| EDC031 | 6 Digits | 88.0x30.0x2.8 | 83.0x18.0 | 8.0x15.0 | Static |
| EDC103 | 8 Digits | 64.0x22.0x2.8 | 60.5x13.5 | 5.14x10.7 | 1/4 Duty |
| ED139 | 6 Digits | 137.16x46.38x2.8 | 130.56x31.5 | 13.2x25.4 | Static |
| EDC190 | 4 Digits | 50.8x30.48x2.8 | 45.72x17.78 | 6.6x13.2 | Static |
| ED233 | 1 Digit | 122.56X81.28 | 109.22x76.2 | 101.6x54.2 | Static |
| EDS803 | 3 1/2 Digits | 50.8x30.48x2.8 | 45.72x16.51 | 6.75x12.7 | Static |
| EDS805 | 4 Digits | 50.8x30.48x2.8 | 45.72x16.51 | 6.6x12.7 | Static |
| EDS806 | 8 Digits | 93.85x30.48x2.8 | 87.5x16.51 | 6.6x12.7 | Static |
| EDS808 | 4 1/2 Digits | 50.8x22.86x2.8 | 45.72x12.7 | 4.63x8.89 | Static |
| EDS809 | 6 Digits | 69.85x30.48x2.8 | 64.77x16.51 | 6.6x12.7 | Static |
| EDS809-1 | 6 Digits | 69.85x30.48x2.8 | 64.77x16.51 | 6.6x12.7 | 1/4 Duty |
| EDS810 | 6 Digits | 93.85x38.1x2.8 | 86.36x24.13 | 9.36x18.0 | Static |
| EDS811 | 4 1/2 Digits | 50.8x30.48x2.8 | 46.8x16.51 | 6.12x11.75 | Static |
| EDS812 | 3 Digits | 30.7x16.2x2.8 | 27.9x10.0 | 4.3x8.0 | Static |
| EDS815 | 4 Digits | 69.85x38.1x2.8 | 62.23x22.86 | 9.0x18.0 | Static |
| EDS816 | 4 Digits | 93.98x45.72x2.8 | 86.36x30.48 | 12.7x25.4 | Static |
| EDS818 | 6 Digits | 63.5x22.86x2.8 | 58.0x12.4 | 5.14x8.89 | Static |
| EDS820 | 5 Digits | 50.8x30.48x2.8 | 45.8x17.8 | 5.2x10.0 | Static |
| EDS825 | 6 Digits | 140.0x46.0x2.8 | 134.0x35.0 | 15.0x30.5 | Static |
| EDS826 | 6 Digits | 40.0x14.0x2.8 | 37.6x9.6 | 4.2x8.0 | 1/4 Duty |
| EDC7683 | LCD Shutter | 101.0x48.5x2.0 | 97.0x42.5 | Static | |
| GDC0121 | PDLC | 133.35x73.15x2.0 | Static | ||
| GD0317 | For air conditioner | 56.5x70.5x2.8 | 49.0x59.0 | 1/4 Duty | |
| EDC6375 | Digital Compass | 98x34.3x2.8 | 92.64x24.94 | 1/4 Duty | |
| GD46532 | For Pressure gauge, safety valve, transmitter | 37.0x25.6x2.8 | 1/4 Duty | ||
