3 V操作霍尔IC/DN8799MSAT
| 价 格： | 面议 | |
| 品牌： | Panasonic/松下 | |
| 型号： | DN8799MSATXL | |
| 种类： | 绝缘栅(MOSFET) | |
| 沟道类型： | N沟道 | |
| 导电方式： | 耗尽型 | |
| 用途： | TUN/调谐 | |
| 封装外形： | SMD(SO)/表面封装 | |
| 材料： | N-FET硅N沟道 | |
| 开启电压： | 18（V） | |
| 夹断电压： | 36（V） | |
| 跨导： | 10（μS） | |
| 极间电容： | 120（pF） | |
| 低频噪声系数： | 10（dB） | |
| 漏极电流： | 10（mA） | |
| 耗散功率： | 120（mW） | |
| 介质材料： | 其他 |
n Overview
The DN8799MS is a 3 V operation Hall IC which
cludes a Hall element, amplifier circuit, Schmidt circuit,
abilized power supply and temperature compensation
rcuit which are integrated on a single chip with a fine
atterning technology. The magnetic input signal is out-
utted by being converted to high or low. We have im-
roved the conventional circuit to realize a stable opera-
on covering from low to high supply voltage and from
w to high temperature.
n Features
Wide operating supply voltage range
(VCC = 2.7 V to 14.4 V)
Wide operating ambient temperature (−40°C to 85°C)
Package: Mini type (3-pin type)
(1.1 mm thick: Same as a standard transistor)
n Applications
Cellular phone (detection of cover open/close), position sensor
1
