MINI USB 8P/F SMT TYPE
| 价 格： | 0.10 | |
| 品牌/商标： | 国产 | |
| 型号/规格： | MINI USB 8P | |
| 应用范围： | 电脑 | |
| 种类： | 排针/排母/排线 | |
| 接口类型： | AC/DC |
Speceifications
Electrical:
Rating:AC 5V/0.5A
Contact Resistance:100M Ohm Min at DC500V
Insulation Resistance:100M Ohm Min at DC 500V
Dielectric Withstanding Voltage:
AC 100V for 1 minute(Cut-off:0.5mA)
Mechanical:
Insertion Fore:35N(3.57Kgf)Max
Withdrawal Fore: 1N(0.1Kgf)Min
Notes:
MATERIAL:
Contact:Phosphor Copper
Front Housing :LCP
Back Housing: LCP
Shell:BRASS
PLATING:
Shell:NICKEL
Contact:GOLD 10U"/TIN
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 王坚波
- 电话：0755-27483253
- 传真：0755-27483253
- 手机：
- QQ ：
深圳排母连接器
信息内容：1.27*2.54mm Female Header Single/Dual Row Straight Current Rating : 1AMPOperation Temperature :-40°C to 105°CContact Resistance :20mΩ MaxInsulation Resistance :1000MΩ MinWithstanding Voltage :AC 500V Insulator Material :Polyester(UL94V-0) Standard:Nylon-6TContact Material :Phosphor BronzeContact plating :Au or Sn Over 50u″ Ni
2.54mm 双排排母连接器
信息内容：2.54mm Female Header Dual Row Straight Current Rating : 3AMPOperation Temperature :-40°C to 105°CContact Resistance :20mΩ MaxInsulation Resistance :1000MΩ MinWithstanding Voltage :AC 1000V Insulator Material :Polyester(UL94V-0) Standard:PBTContact Material :Phosphor BronzeContact plating :Au or Sn Over 50u″ Ni
