SICK施克MZT6-03VPS-KR0磁性气缸传感器
| 价 格： | 面议 | |
| 品牌/商标： | SICK/施克 | |
| 型号/规格： | MZT6-03VPS-KR0 | |
| 种类： | 磁敏 | |
| 材料： | 混合物 | |
| 材料物理性质： | 磁性材料 | |
| 材料晶体结构： | 单晶 | |
| 制作工艺： | 集成 | |
| 输出信号： | 数字型 | |
| 防护等级： | IP 68 | |
| 线性度： | NO（%F.S.） | |
| 迟滞： | NO（%F.S.） | |
| 重复性： | 0.1MT（%F.S.） | |
| 灵敏度： | 2.6 mT | |
| 漂移： | NO | |
| 分辨率： | 1,000赫兹 |
Magnetic Cylinder Sensors
Magnetic cylinder sensor, DC 3-wire, for T-slot cylinders
Model Name MZT6-03VPS-KR0
Part No. 1023972
With new ASIC for maximum switching accuracy
Mountable from the top
For all common used T-slot cylinder
Plastic housing with nickel silver bushing and hexagon socket/sloted screw
LED function indicator
Enclosure rating IP 68, IP 69K
Product features
Sensing face: Front
Switching output voltage: PNP
Output function: Normally open
Switching frequency: 1,000 Hz
Connection type: Cable with plug, M8, 3-pin, w. knurled screws, PUR, 0.5 m
Technical data
Length: 31.5 mm
Supply voltage: DC 10 ... 30 V
Ripple: <= 10 %
Power consumption: <= 10 mA
Response sensitivity: 2.6 mT
Continuous current: <= 200 mA
Reproducibility: (Ub and Ta constant), <= 0.1 mT (Ub and Ta constant)
EMC: according to EN 60947-5-2
Wire-break protection:
Short-circuit protection (pulsed):
Reverse polarity protection:
Power-up pulse suppression:
Enclosure rating: IP 68
Ambient temperature min ... max: -30 °C ... 80 °C
Housing material: plastic
Overrun distance typ.: 3 mm
Voltage drop: <= 2.2 V
Dimensions (W x H x L): 31.5 mm
Ex-i: 0
ATEX: 0
- 所属城市：江西 南昌
- [联系时请说明来自维库仪器仪表网]
- 联系人： 花方久
- 电话：0791-6176886
- 传真：0791-6176886
- 手机：
- QQ ：
特价供应TURCK图尔克位置传感器BI2-CRS343-AP4X2-H1141/S34
