0402贴片电感1005高频电感1.6nH
| 价 格： | 0.20 | |
| 安装方式： | 其他 | |
| 电感量： | 1（mH） | |
| 额定电流： | 1（mA） | |
| 种类： | 电流互感器 | |
| 磁芯形状： | 柱形 | |
| 导磁体性质： | 铁氧体磁芯 | |
| 标称电压： | 1（V） | |
| 允许误差： | 1 | |
| 应用范围： | 滤波 | |
| 品质因数Q： | 800 | |
| 封装形式： | 贴片电感 | |
| 骨架材料： | 陶瓷 | |
| 型号： | MGCI100T3N3ST | |
| 工作频率： | 低频 | |
| 分布电容： | 1（F） | |
| 绕线形式： | 单层间绕式 | |
| 品牌： | 国产 | |
| 感抗XL： | 1（Ω） |
生产贴片电感贴片高频电感贴
供应片式贴片绕线电感
Part No | L (uH) | DCR max (mΩ) | IDC max (A) | Test Freq. (Hz) |
| 1.Inductance tested at 2.52MHZ,0.1V
Packing; Reel size:16mm Quantity:1000pcs/Reel |
MGTC1005-47N | 0.047 | 0.45 | 25 | 50KHZ | ||
MGTC1005-56N | 0.056 | 0.45 | 25 | 50KHZ | ||
MGTC1005-68N | 0.068 | 0.45 | 25 | 50KHZ | ||
MGTC1005-82N | 0.082 | 0.45 | 25 | 50KHZ | ||
MGTC1005-R10 | 0.1 | 0.7 | 25 | 25KHZ | ||
MGTC1005-R12 | 0.12 | 0.7 | 25 | 25KHZ | ||
MGTC1005-R15 | 0.15 | 0.9 | 25 | 25KHZ | ||
MGTC1005-R18 | 0.18 | 1.1 | 25 | 25KHZ | ||
MGTC1005-R22 | 0.22 | 1.2 | 25 | 25KHZ | ||
MGTC1005-R27 | 0.27 | 1.2 | 25 | 25KHZ | ||
MGTC1005-R33 | 0.33 | 1.25 | 25 | 25KHZ | ||
MGTC1005-R39 | 0.39 | 1.5 | 18 | 25KHZ | ||
MGTC1005-R47 | 0.47 | 2 | 18 | 25KHZ | ||
MGTC1005-R56 | 0.56 | 2.35 | 18 | 25KHZ | ||
MGTC1005-R68 | 0.68 | 2.55 | 18 | 25KHZ | ||
MGTC1005-R82 | 0.82 | 3.15 | 18 | 25KHZ | ||
MGTC1005-1R0 | 1 | 0.9 | 18 | 10KHZ | ||
MGTC1005-1R2 | 1.2 | 1.2 | 15 | 10KHZ | ||
MGTC1005-1R5 | 1.5 | 1.2 | 15 | 10KHZ |
Special i nquir1ies besides the above common used types can be met on your requirement.
