RZ3A三相交流固态继电器 RZ3AThree Phase AC Solid State Relay ACOutput 面板安装固态继电器
25-120Amp 400/600VAC | dzsc/19/0420/19042061.jpg
| ● 高性能,100%实电流测试 ● 纯新进口元器件封装,品质保证 ● 数位孔化板,SMD贴装工艺 ● LED发光管工作状态指示,IP20安全防护盖 ● DBC铜瓷键合基板,热循环次数高 ● 内置RC吸收电路,欧盟CE认证 | ● High-performance, 100% of actual current test ● Pure new import component packaging, quality assurance ● Hole of the digital board, SMD mount technology ● LED LED working status indicator, IP20 safety protection cap ● DCB copper bonded ceramic substrates, the high number of thermal cycling ● Built-in RC snubber circuit, the European Union CE Certification | | |
三相交流固态继电器 | 工作电压范围 Operating Voltage (47-63Hz): 40:42-480VAC, 60:75-660VAC | 峰值电压 Transient Overvoltage: 850Vp .1600Vp | 工作电流范围 Maximun Load Current: 0.15-25A,40A,55,60A,75A, 100A, 120A | 断态漏电流 Maximum Off-State Leakage Current: ≤3mA | 应答动作时间 Maximum Turn-On off Time: ON≤10mS, Off≤10mS | 绝缘电压 Dielectric Strength, Input/Output/Base:≥2500VAC 1Mni | 绝缘强度 Minimum Insulation Resistance: 500MΩ/500VDC | 工作温度 Ambient Operating Temperature Range: -20℃~ 70℃ | 详细技术参数表: | 点击PDF文件 |
|
