供应 优质 0.4英寸绿色 双位数码管
| 价 格： | 1.00 | |
| 是否提供加工定制： | 是 | |
| 种类： | LED数码管 | |
| 型号/规格： | BL-D43A-21G-21 | |
| 品牌/商标： | BETLUX | |
| 显示颜色： | 全彩 | |
| 显示方式： | 垂直滚动 | |
| 像素直径： | Ф3（mm） | |
| 像素间距： | 标准（mm） | |
| 模组尺寸： | 标准（mm） | |
| 屏幕尺寸： | 标准（英寸） | |
| 亮度： | 高亮 | |
| 灰度： | 标准 | |
| 像素： | 标准 | |
| 分辨率： | 标准 | |
| 安装方式： | 镶嵌式 |
特点:
0.4英寸双位LED数码管
0.4英寸数字高度（11.00mm）
宽*高：23.80*18.80mm ；
低电流操作
共阴共阳可选
易于安装
IC兼容
标准：灰面白字
n Super Bright
Electrical-optical characteristics: (Ta=25°C) (Test Condition: IF=20mA)
Part No | Chip | VF Unit:V | Iv TYP.(mcd) | |||||
Common Cathode | Common Anode | Emitted Color | Material | lP (nm) | ||||
Typ | Max | |||||||
BL-D43A-21S-XX | BL-D43B-21S-XX | Hi Red | GaAlAs/GaAs,SH | 660 | 1.85 | 2.20 | 100 |
|
BL-D43A-21D-XX | BL-D43B-21D-XX | Super Red | GaAlAs/GaAs,DH | 660 | 1.85 | 2.20 | 160 |
|
BL-D43A-21UR-XX | BL-D43B-21UR-XX | Ultra Red | GaAlAs/GaAs,DDH | 660 | 1.85 | 2.20 | 190 |
|
BL-D43A-21E-XX | BL-D43B-21E-XX | Orange | GaAsP/GaP | 635 | 2.10 | 2.50 | 60 |
|
BL-D43A-21Y-XX | BL-D43B-21Y-XX | Yellow | GaAsP/GaP | 585 | 2.10 | 2.50 | 55 |
|
BL-D43A-21G-XX | BL-D43B-21G-XX | Green | GaP/GaP | 570 | 2.20 | 2.50 | 40 |
|
n Ultra Bright
Electrical-optical characteristics: (Ta=25°C) (Test Condition: IF=20mA)
Part No | Chip | VF Unit:V | Iv TYP.(mcd) | |||||
Common Cathode | Common Anode | Emitted Color | Material | lP (nm) | ||||
Typ | Max | |||||||
BL-D43A-21UHR-XX | BL-D43B-21UHR-XX | Ultra Red | AlGaInP | 645 | 2.10 | 2.50 | 190 |
|
BL-D43A-21UE-XX | BL-D43B-21UE-XX | Ultra Orange | AlGaInP | 630 | 2.10 | 2.50 | 120 |
|
BL-D43A-21YO-XX | BL-D43B-21YO-XX | Ultra Amber | AlGaInP | 619 | 2.10 | 2.50 | 120 |
|
BL-D43A-21UY-XX | BL-D43B-21UY-XX | Ultra Yellow | AlGaInP | 590 | 2.10 | 2.50 | 120 |
|
BL-D43A-21UG-XX | BL-D43B-21UG-XX | Ultra Green | AlGaInP | 574 | 2.20 | 2.50 | 115 |
|
BL-D43A-21PG-XX | BL-D43B-21PG-XX | Ultra Pure Green | InGaN | 525 | 3.80 | 4.50 | 185 |
|
BL-D43A-21B-XX | BL-D43B-21B-XX | Ultra Blue | InGaN | 470 | 2.70 | 4.20 | 75 |
|
BL-D43A-21W-XX | BL-D43B-21W-XX | Ultra White | InGaN | / | 2.70 | 4.20 | 75 |
|
n -XX: Surface / Lens color：
Number | 0 | 1 | 2 | 3 | 4 | 5 |
Ref Surface Color | White | Black | Gray | Red | Green |
|
Epoxy Color | Water clear | White diffused | Red Diffused | Green Diffused | Yellow Diffused |
|
dzsc/19/0186/19018672.jpg
