MS9010.D惯性加速度传感器
| 价 格： | 面议 | |
| 型号/规格： | MS9010.D | |
| 品牌/商标： | COLIBRYS |
型号：MS9010.D惯性加速度传感器
量程：单轴±10g
封装：LCC20
抗冲击性能：6000g
灵敏度：200±2mv/g
温漂：＜0.5mg/℃
带宽：0 to≥100Hz
输出方式：0.5~4.5v模拟输出
备注：尺寸：8.9×8.9×3.23毫米，精度高、稳定性好、耐高温，可用于石油随钻。
MS9000.D Features:
− ±1g to ±200g range
− Excellent bias stability (less than 0.05% of full scale)
− Single power supply (+2.5V to +5.5V, ratiometric voltage output)
− Low power
− Extra small 20 pin LCC ceramic package with hermetic sealing (8.9mm x 8.9mm)
− Individually calibrated (bias, scale factor and non linearity)
− Brown out protected
− RoHS compliant suitable for lead free soldering process and SMD mounting
- 所属城市：北京 北京市
- [联系时请说明来自维库仪器仪表网]
- 联系人： 李先生/张小姐
- 电话：010-82533208
- 传真：010-82533708
- 手机：18611926055
- QQ ：
MS9005.D惯性加速度传感器
信息内容：型号：MS9005.D惯性加速度传感器 量程：单轴±5g 封装：LCC20 抗冲击性能：6000g 灵敏度：400±4mv/g 温漂：＜0. 25mg/℃ 带宽：0 to≥100Hz 输出方式：0.5~4.5v模拟输出 备注：尺寸：8.9×8.9×3.23毫米，精度高、稳定性好、耐高温 MS9000.D Features: − ±1g to ±200g range − Excellent bias stability (less than 0.05% of full scale) − Single power supply (+2.5V to +5.5V, ratiometric voltage output) − Low power − Extra small 20 pin LCC ceramic package with hermetic sealing (8.9mm x 8.9mm) − Individually calibrated (bias, scale factor and non linearity) − Brown out protected − RoHS compliant suitable for lead free soldering process and SMD mounting
MS9002.D惯性加速度传感器
信息内容：型号：MS9002.D惯性加速度传感器 量程：单轴±2g 封装：LCC20 抗冲击性能：6000g 灵敏度：1000±8mv/g 温漂：＜0.1mg/℃ 带宽：0 to≥100Hz 输出方式：0.5~4.5v模拟输出 MS9000.D Features: − ±1g to ±200g range − Excellent bias stability (less than 0.05% of full scale) − Single power supply (+2.5V to +5.5V, ratiometric voltage output) − Low power − Extra small 20 pin LCC ceramic package with hermetic sealing (8.9mm x 8.9mm) − Individually calibrated (bias, scale factor and non linearity) − Brown out protected − RoHS compliant suitable for lead free soldering process and SMD mounting
