电池连接器系列
| 价 格： | 0.10 | |
| 是否提供加工定制： | 否 | |
| 品牌/商标： | 国产 | |
| 型号/规格： | Battery | |
| 应用范围： | 电脑 | |
| 种类： | 插头/插座 | |
| 接口类型： | AC/DC |
电池连接器系列 Battery Connectors Series
Rated voltage:5V
Rated current:0.5A
Contact resistance:≤40mΩ
Insulation resistance:≥500mΩ
Withstanding voltage:500V AC
Temp range for usage:-20°C～ 85°C
MATERIAL
Plastic Parts:LCP UL94V-0
Contact Point:Phos. Copper Gold-Plated
PACKAGE
Tape and Reel Package
Pipe Package
Bag Package
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 王坚波
- 电话：0755-27483253
- 传真：0755-27483253
- 手机：
- QQ ：
连接器 排针
信息内容：1.27mm Board Spacer Dual Row Straight /Right Angle Current Rating : 1AMPOperation Temperature :-40°C to 105°CContact Resistance :20mΩ MaxInsulation Resistance :1000MΩ MinWithstanding Voltage :AC 500V Insulator Material :Polyester(UL94V-0) Standard:Nylon -6TContact Material :BrassContact plating :Au or Sn Over 50u″ Ni
1.27mm Female Header Dual Row Side Entry Right An
信息内容：Current Rating : 1AMPOperation Temperature :-40°C to 105°CContact Resistance :20mΩ MaxInsulation Resistance :1000MΩ MinWithstanding Voltage :AC 500V Insulator Material :Polyester(UL94V-0) Standard:Nylon -6TContact Material :Phosphor BronzeContact plating :Au or Sn Over 50u″ Ni "
