中性白LXA7-PW40色温4000K显指70以上飞利浦大功率LED光源
| 价 格： | 10.99 | |
| 颜色： | 白色 | |
| 型号/规格： | LXA7-PW40 | |
| 品牌/商标： | PHILIPS/飞利浦 | |
| 种类： | 发光二极管 | |
| 加工定制： | 否 |
LUXEON R,
• Freedom From Binning for superior quality of light
• Hot tested at real world conditions of 700 mA and Tj = 85°C
• Maximum light output and lowest cost of light
• Simplified design and accelerated time to market
• Specified typical 75 CRI and minimum 70 CRI at 700 mA, Tj = 85°C.
| LUXEON R系列 | ||||||||||||
| Color | CCT | Part Number | Typical Luminous Flux(lm) | CRI | Bin Code | Flux Bins(lm) | Bin Code | Vf Bins(V) | ||||
| @ 350 mA | @ 700 mA | @ 1000 mA | G | 160--170 | P | 2.5--2.75 | ||||||
| Warm-White | 3000K | LXA7-PW30 | 100 | 180 | 245 | 70--75 | H | 170--180 | R | 2.75--3.0 | ||
| Neutral-White | 4000K | LXA7-PW40 | 119 | 215 | 292 | 70--75 | J | 180--190 | S | 3.0--3.25 | ||
| Cool-White | 5000K | LXA7-PW50 | 122 | 220 | 299 | 70--75 | K | 190--200 | ||||
| Cool-White | 5700K | LXA7-PW57 | 122 | 220 | 299 | 70--75 | L | 200--210 | ||||
| Cool-White | 6500K | LXA7-PW65 | 122 | 220 | 299 | 70--75 | M | 210--220 | ||||
| N | 220--230 | |||||||||||
| P | 230--240 | |||||||||||
| Q | 240--255 | |||||||||||
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 伍淑东
- 电话：
- 传真：
- 手机：18923460326
- QQ ：
供应588nm591nm592nm黄光PC琥珀色LXM2-PL01-0090大功率LED
信息内容：Rebel & Rebel ES系列ColorWavelengthPart NumberTypical Luminous Flux(lm)Color Bins(nm)TypEfficacy@ 350 mA@ 700 mARed-Orange610nm617nm620nmLXM2-PH01-00707213483LXM2-PH01-006067122[2] 610--62076LXML-PH01-00606210040LXML-PH01-0050569035PC Amber588nm591nm592nmLXM2-PL01-00909116473LXM2-PL01-008084151[1] 584.5--58768LXM2-PL01-007078140[2] 587--589.563LXM2-PL01-006069124[4] 589.5--59255Amber584.5nm590nm597nmLXML-PL01-00606198[6] 592--594.539LXML-PL01-00505484[7] 594.5--59733LXML-PL01-0040487730LXML-PL01-0030386124 dzsc/18/9381/18938190.jpg
冷白色光欧司朗大功率LED6500K色温130流明
信息内容：LUW W5AM-KZLY-6P7R色温：6500K亮度：97--150LM Features•package: white SMD package, colorless clear silicone resin, clear silicone lens, chip level conversion•typical Luminous Flux: 105 lm at 350 mA•feature of the device: high efficient lightsource at low space•color coordinates: x = 0.31, y = 0.32 acc. to CIE 1931 (white)•typ. color temperature: 6500 K•viewing angle: 170°•technology: ThinGaN®•optical efficiency: 93 lm/W•grouping parameter: luminous flux, color coordinates•assembly methods: suitable for all SMT assembly methods•soldering methods: reflow soldering•preconditioning: acc. to JEDEC Level 4•taping: 24 mm tape with 200/reel, ø180 mm•ESD-withstand voltage: up to 2 kV acc. to JESD22-A114-D LUW W5AM-KZLY-6P7R色温：6500K亮度：97 ... 150LM dzsc/18/9385/18938506.jpg
