专销霍尼韦尔honeywell触力传感器FSS1500NST
| 价 格： | 0.10 | |
| 是否提供加工定制： | 是 | |
| 品牌： | 专销霍尼韦尔honeywell | |
| 型号： | 专销霍尼韦尔honeywellFSS1500NST | |
| 种类： | 压力 | |
| 材料物理性质： | 半导体 | |
| 材料晶体结构： | 多晶 | |
| 制作工艺： | 集成 | |
| 输出信号： | 4 kOhm min., 5 kOhm typ., 6 kOhm max. | |
| 防护等级： | ESD 8 kV | |
| 线性度： | ±1.5% Span, BFSL（%F.S.） | |
| 重复性： | 0 g to 1500 g（%F.S.） | |
| 灵敏度： | 0.10 mV/g min., 0.12 mV/g typ., 0.14 mV/g max |
dzsc/18/9324/18932498.jpg
dzsc/18/9324/18932498.jpg
dzsc/18/9324/18932498.jpg
| Sensitivity | 0.10 mV/g min., 0.12 mV/g typ., 0.14 mV/g max. |
| Operating Force (OF) | 0 g to 1500 g |
| Supply Voltage | 5.0 Vdc typ., 12.0 Vdc max. |
| Null Offset | ±15 mV |
| Linearity | ±1.5% Span, BFSL |
| Null Shift over Temperature | ±0.5 mV typ. |
| Sensitivity Shift over Temperature | ±5.5% span |
| Input Resistance | 4.0 kOhm min., 5.0 kOhm typ., 6.0 kOhm max. |
| Output Resistance | 4 kOhm min., 5 kOhm typ., 6 kOhm max. |
| Overforce | 4,500 g |
| ESD | 8 kV |
| Operating Temperature | -40 °C to 85 °C [-40 °F to 185 °F] |
| Storage Temperature | -40 °C to 100 °C [-40 °F to 212 °F] |
| Vibration | 10 Hz to 2 kHz, 20 g, sine |
| Shock | 150 g, 6 ms, half sine |
| Solderability | 5 s at 315 °C per lead |
| Availability | Global |
| Comment | MCTF 20 Million at 50 °C |
| UNSPSC Code | 411121 |
| UNSPSC Commodity | 411121 Transducers |
| Package Type | Tube |
| Series Name | FSS |
- 所属城市：上海
- [联系时请说明来自维库仪器仪表网]
- 联系人： 王稳
- 电话：
- 传真：
- 手机：
- QQ ：
销售baumer堡盟宝盟电感式接近开关IFFM08,04,06经销与服务等
