原装进口飞利浦大功率3500K投光灯路灯室内照明灯用LXW8-PW35
| 价 格： | 9.01 | |
| 加工定制： | 否 | |
| 种类： | 发光二极管 | |
| 型号/规格： | LXW8-PW35 | |
| 品牌/商标： | PHILIPS/飞利浦 | |
| 颜色： | 白色 |
dzsc/18/9278/18927855.jpg
色温 | 型号 | 功率 | 光通量 | 电压 | CRI | 发光角度 |
4100K | LXML-PWN2 | 1W 2W 3W | 130lm @ 350mA 235lm @ 700mA 320lm @ 1000mA | 2.85V 3.0V 3.1V | 65 | 120度 |
5650K | LXML-PWC2 | 1W 2W 3W | 135lm @ 350mA 230lm @ 700mA 310lm @ 1000mA | 2.85V 3.0V 3.1V | 70 | 120度 |
2700K | LXW9-PW27 | 1W 2W 3W | 75lm @ 350mA 135lm @ 700mA 184lm @ 1000mA | 2.85V 3.0V 3.1V | 95 | 120度 |
3000K | LXW9-PW30 | 1W 2W 3W | 81lm @ 350mA 145lm @ 700mA 197lm @ 1000mA | 2.85V 3.0V 3.1V | 95 | 120度 |
3500K | LXW8-PW35 | 1W 2W 3W | 103lm @ 350mA 185lm @ 700mA 252lm @ 1000mA | 2.85V 3.0V 3.1V | 85 | 120度 |
4000K | LXH7-PW40 | 1W 2W 3W | 114lm @ 350mA 205lm @ 700mA 279lm @ 1000mA | 2.85V 3.0V 3.1V | 75 | 120度 |
4000K | LXW8-PW40 | 1W 2W 3W | 106lm @ 350mA 190lm @ 700mA 258lm @ 1000mA | 2.85V 3.0V 3.1V | 85 | 120度 |
5000K | LXW8-PW50 | 1W 2W 3W | 111lm @ 350mA 200lm @ 700mA 272lm @ 1000mA | 2.85V 3.0V 3.1V | 85 | 120度 |
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 伍淑东
- 电话：
- 传真：
- 手机：18923460326
- QQ ：
5600K色温15W6个芯片OSTAR大功率LED
信息内容：Features•package: OSTAR® - Lighting•feature of the device: outstanding brightness and luminance due to pure surface emission and low Rth•color coordinates: x = 0.33, y = 0.33 acc. to CIE 1931 (white)•typ. color temperature: 5600 K•color reproduction index: 80•viewing angle: 130°•light emitting surface: 2.1 mm x 3.2 mm•technology: ThInGaN®•Luminance: 14.5*106 cd/m²•optical efficiency: 50 lm/W at 350 mA•mounting methods: screw holessolder pads for wire attachment•ESD-withstand voltage: up to 2 kV acc. to JESD22-A114-Cmethod of packing: 60 pcs. per trayApplications•General lighting•microscope illumination•VMS (variable message signs)•high end strobe light
ANSI 4000K CRI 85 飞利浦LXW8-PW40大功率LED
信息内容：NominalCCTCCTRangeMinCRITypicalCRIMinFluxTyp Flux @350 mA Typ Efficacy lm/w@ 350 mA PartNumberANSI 3000K 909512014569LXW9-PW30*ANSI 2700K 909512013564LXW9-PW27*ANSI 3000K 8590506663LXML-PW71 2540K-3500K 85606562LXML-PWW1-0060 2540K-3500K 85505552LXML-PWW1-0050ANSI 5000K 8085180200111LXW8-PW50*ANSI 4000K 8085170190106LXW8-PW40*ANSI 3500K 8085160185103LXW8-PW35*ANSI 4000K 8085809590LXM3-PW51ANSI 3000K 8085758581LXM8-PW30ANSI 3500K 8085708076LXM3-PW61ANSI 2700K 8085708076LXM8-PW27ANSI 3000K 8085707773LXM3-PW71ANSI 2700K 8085657370LXM3-PW81ANSI 4000K 707518020598LXH7-PW40*ANSI 4000K 70759010095LXM7-PW40 4500K-10000K6070200235135LXML-PWC2* 4500K-10000K 70120130124LXML-PWC1-0120 4500-10000K 70100110105LXML-PWC1-0100 4500-10000K 70909586LXML-PWC1-0090 3500K-4500K 70100110105LXML-PWN1-0100 3500K-4500K 70909591LXML-PWN1-0090ANSI 6500K 657090105100LXML-PW11ANSI 5700K 657090105100LXML-PW21ANSI 5000K 657090105100LXML-PW31 3500K-4500K6065200230130LXML-PWN2* 3500K - 4500K 65120130124LXML-PWN1-01...
