供应DELPHI连接器汽车密封防水连接器，防水塞，15366060
| 价 格： | 面议 | |
| 加工定制： | 否 | |
| 品牌/商标： | Delphi/德尔福 | |
| 型号/规格： | 15366060 | |
| 应用范围： | 汽车 | |
| 种类： | 防水塞 | |
| 接口类型： | AC/DC | |
| 形状： | 圆形 | |
| 制作工艺： | 注塑 | |
| 特性： | 防水 | |
| 工作频率： | 其他 | |
| 接触件材质： | Nylon |
15366060技术资料
| Product Number | 15366060 |
| Description | Blue Individual Loose Cable Seal |
| Search Max Cable Diameter Range mm | 2.0-2.9 |
| Search Min Cable Diameter Range mm | 1.0-1.9 |
| Max Cable Diameter | 2.40 |
| Min Cable Diameter | 1.86 |
| Cable Seal Type | Individual Loose |
| Product Type | Seal |
| Family | Cable |
| Series | GT |
| Cavity Quantity | 1 |
| Seal Outside Diameter | 4.50 |
| Color | Blue |
| Shape | Round |
| Status | Active |
| Part Volume | 0.036 cm3 |
| Part Weight | 0.04968 g |
15366060图纸
dzsc/18/9237/18923702.jpg
