| 产品规格 | | | | 表面安装分类 | Yes | | 工艺 | MULTI-LAYER | | 形状 | Chip | | 电路数 | Nom | 1 | | | 材质名称 | D | | 尺寸代码 | 1608 | | 主体横宽(L) | Nom | 1.6 m | m | | 主体纵长(W) | Nom | 0.8 m | m | | 主体高度(T) | Nom | 0.8 m | m | | 阻抗 | Min | 180 | Ohm | | 阻抗 | Nom | 240 | Ohm | | 阻抗容差 | Min | -25 | % | | Max | 25 | % | | 阻抗测定频率 | Nom | 100 M | Hz | | 额定电流 | Max | 0.3 | A | | 直流电阻 | Max | 0.6 | Ohm | | 适用焊接方法 | Flow,Reflow,Iron Soldering | | 分类温度范围 | Min | -55 | Cel | | Max | 125 | Cel | | 保存温度范围 | Min | -55 | Cel | | Max | 125 | Cel | | 重量 | Nom | 0.003 | g |
| | | 概要/用途/特点 | | | | 概要 | The MMZ series provide effective EMC suppression in signal lines through simple in-series implementation. It is applicable for lead free soldering. | | 用途 | PC,DVD,CDMA,LCD,PDC | | 特点 | The MMZ series provide effective EMC suppression in signal lines through simple in-series implementation.
High SRF characteristic.
It is applicable for lead free soldering. |
| 包装信息 | | | | 包装形式 | Punched (Paper)Taping [180mm Reel] | | 最少包装数 | Nom | 4000 | Pcs | | 最少供货数 | Nom | 4000 | Pcs | | |  |
|
