172165-1 TYCO STOCK

172165-1  TYCO PRELIMINARY SUMMARY: CONNECTOR DATASHEET PDF.ENQUIRY HOTLINE: 0086 755 8399 5017, EMAIL:Kevin[at]parkeli.com. ≡≡Parkeli.com≡≡ TYCO OnlyNew and Original, TYCO Stock Shipped 1 Day. Lead Time Only 2 Weeks.

Manufacturer TE Connectivity
Manufacturer Part Number 172165-1
Description CONN PLUG 2POS MINI UNIV-MATE
Lead Free Status / RoHS Status Lead free / RoHS Compliant
Datasheets 172165

Product Photos 172165-1

Catalog Drawings Plug In-Line Side
Plug In-Line

3D Model 172165-1

Standard Package 1,000
Category Connectors, Interconnects
Family Rectangular - Housings
Series Mini-Universal MATE-N-LOK®
Connector Type Plug

Contact Type Male or Female

Number of Positions 2

Pitch 0.163" (4.14mm)

Number of Rows 1

Row Spacing -

Mounting Type Free Hanging (In-Line)

Contact Termination Crimp

Fastening Type Latch Lock

Color Natural

Features -

Packaging Bulk

Note Contacts Not Provided

Catalog Page 242 (US2011 Interactive)
242 (US2011 PDF)

Mating Products 1-172343-6-ND - CONN CAP 2POS MINI-U-MNL BLUE
1-172343-5-ND - CONN CAP 2POS MINI-U-MNL GREEN
1-172343-2-ND - CONN CAP 2POS MINI-U-MNL RED
1-172233-5-ND - CONN CAP 2POS MINI-U-MNL GREEN
1-172233-2-ND - CONN CAP 2POS MINI-U-MNL RED
1-172157-6-ND - CONN CAP 2POS MINI-U-MNL BLUE
1-172157-5-ND - CONN CAP 2POS MINI-U-MNL GREEN
1-172157-2-ND - CONN CAP RCPT 2POS MINI-UM-N-L
1-172157-9-ND - CONN RCPT HOUSING 2POS .163"
1-172233-9-ND - CONN CAP 2POS MINI UNIV-MNL BLK
More...

Associated Product A100437CT-ND - CONN SOCKT 20-16AWG MINI-UMNL AU
A100438CT-ND - CONN SOCKT 20-16AWG MINI-UMNL AU
A100828CT-ND - CONN SOCKET 20-16AWG M-UNML TIN
A100438TR-ND - CONN SOCKT 20-16AWG MINI-UMNL AU
A100437TR-ND - CONN SOCKT 20-16AWG MINI-UMNL AU
A100436TR-ND - CONN PIN 20-16AWG MINI-UMNL GOLD
1-770988-1-ND - CONN SOCKET 22-18AWG MINI-UMNL
A100430TR-ND - CONN SOCKT 22-18AWG MINI-UMNL AU
1-770903-1-ND - CONN PIN 22-18AWG MINI-UMNL GOLD
A100429TR-ND - CONN SOCKT 26-22AWG MINI-UMNL AU
More...

Other Names A25587

PRODUCT IMAGE:

 Manufacturer Part No:  172165-1
Manufacturer:  Tyco Electronics / AMP
Description:  Pin & Socket Connectors 2 CIRCUIT PLUG
Manufacturer:  Tyco Electronics

Product Category:  Pin & Socket Connectors

RoHS:   Details

Series:  MATE-N-LOK

Product Type:  Receptacle Housings

Contact Gender:  Pin (Male)

Number of Positions / Contacts:  2

Mounting Style:  Free Hanging

Termination Style:  Crimp

Housing Material:  Polyamide

Voltage Rating:  600 V

Current Rating:  9.5 A

Packaging:  Bulk

Standard Pack Qty:  1000

Wire Gauge Range:  30-16
 PRODUCT IMAGE:

.163" Centerline, 600 V, 9.5 A max.
 Always EU RoHS/ELV Compliant (Statement of Compliance)
Product Highlights:
Connector
Housing
Connector Style = Plug
Mini-Universal MATE-N-LOK
4.14 mm Centerline
 Product Type Features:
Product Type = Connector
Connector Type = Housing
Connector Line = Mini-Universal MATE-N-LOK
Mount = Free Hanging
Color = Natural

Mechanical Attachment:
Mating Retention Type = Positive Lock

Electrical Characteristics:
Voltage (VAC) = 600

Body Features:
Centerline (mm [in]) = 4.14 [0.163]
Number of Positions = 2
Mating Retention = With
Contact Diameter (mm [in]) = 0.99 [0.039]
Contact Features:
Contact Layout = In-Line

Housing Features:
Connector Style = Plug
Housing Material = Nylon
UL Flammability Rating = UL 94V-0

Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Always was RoHS compliant

Other:
Brand = AMP

 PRODUCT IMAGE:

TYCO CONNECTORS STOCKENQUIRY HOTLINE: 0086 755 8399 5017, EMAIL: Kevin[at]parkeli.com, ≡≡Parkeli.com≡≡
