3M 穿刺连接器,电缆连接头,穿刺线夹,电缆连接头
| 价 格： | 面议 | |
| 是否提供加工定制： | 否 | |
| 品牌/商标： | 3M | |
| 型号/规格： | 316IR | |
| 应用范围： | 电缆 | |
| 种类： | 端子(terminal) | |
| 接口类型： | IDC | |
| 支持卡数： | 二合一 | |
| 读卡类型： | SD | |
| 形状： | 圆形 | |
| 制作工艺： | 冷压 | |
| 特性： | 防潮 | |
| 接触件材质： | pvc | |
| 绝缘体材质： | pvc | |
| 芯数： | 2 | |
| 针数： | 2 | |
| 线长： | 2（mm） |
Use 3M™ Scotchlok™ Electrical IDCs 316IR to electrically connect two or three wire ends, insulate the connection and provide a moisture resistant seal. Recommended for use with low energy underground circuit wires, sprinkler systems, landscape lighting or other moisture resistance wires for applications of less than 30 volts. Sealant is a mineral oil-based grease. Maximum insulation O.D.diameter of 0.155 inches (3,9 mm) and a operating temperature of 221°F (105°C). The suggested application tool for this connector is the E-9BM Crimping Tool.
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 黎彩玲
- 电话：0755-28178863
- 传真：0755-28178863
- 手机：
- QQ ：
供应3M,314U,端子连接器
信息内容：ApplicationUse Part No. 314U to electrically connect two or threewire ends and insulate the connection.Wire Range22-14 AWG Solid or stranded, tinned or untinned(0,5-1.5 mm2) copper conductors. For use withcommon thermoplastic insulated wires: T, TF, TFF,TFN, TFFN, AWM, TEW, SAE-GPT with a maximuminsulation diameter of .150 inches (3,8 mm). Maximumrecommended current for general purpose applications:22 AWG - 3 AMPS, 20 AWG - 5 AMPS, 18 AWG -7 AMPS, 16 AWG - 10 AMPS, 14 AWG - 15 AMPS.
特价汽车连接器
信息内容：Wire Range22-16 AWG Solid or stranded, tinned or untinned(.5-1.5 mm2 str.) copper conductors. For use withcommon thermoplastic insulated wires such as: T, TF,TFF, TFN, TFFN, AWM, TEW, SAE-GPT with amaximum insulation diameter of .120 inches (3,0 mm).Maximum recommended current for general purposeapplications: 22 AWG - 3 AMPS, 20 AWG - 4 AMPS,18 AWG - 7 AMPS, 16 AWG - 10 AMPS.ConstructionU-contact - Tin plated brass, .02 in. (.5 mm) thickInsulator - Flame retardant polypropylene,Color - red
