供应日本广濑HRS 0.4 20P 板对板连接器 DF30RB-20DP-0.4V(82)

价格：		1.00
加工定制：		否
品牌/商标：		Hirose/广濑
型号/规格：		DF30RB-20DP-0.4V(82)
应用范围：		手机
种类：		板对板
接口类型：		ZIF
支持卡数：		单卡
接触件材质：		DF30RB-20DP-0.4V(82)
绝缘体材质：		DF30RB-20DP-0.4V(82)
芯数：		DF30RB-20DP-0.4V(82)
针数：		20
线长：		0.00（mm）

详细介绍
企业详情

DF30 Series

dzsc/18/8984/18898416.jpg			-Features
			●	Space saving design with miniaturized PCB mounting area to the maximum contributes to high-density packaging of application.
			●	Dimples on header contact enhances wiping operation, which improves contact reliability.
			●	Wide self alignment range on the receptacle surface to ensure high mating reliability in a limited space.
			●	Varieties of No. of positions, especially small number for LCD and camera module connections for mobile phones.
			●	Wide vacuum pick up area for automatic mounting in spite of ultra small.
dzsc/18/8984/18898416.jpg	dzsc/18/8984/18898416.jpg	dzsc/18/8984/18898416.jpg	-Applications
		Photograph_Help
dzsc/18/8984/18898416.jpg	dzsc/18/8984/18898416.jpg
	733KB

-Specifications Help

Characteristic	Specifications
No. of Positions	10, 14, 20, 22, 24, 30, 34, 40, 44, 50, 60, 70, 80
Current Rating(Amps)(Max.)	0.3
PCB Mount Type	SMT
Contact Mating Area Plating	Gold
Terminal Pitch (mm)	0.4
Contact Spacing (mm)	0.4
Stack Height (mm)	0.9
Operating Temperature Range (degrees C)	-35 to 85
Connector Type	Board mounting
Contact Gender	Female, Male

本公司经销各种各类接插件，AMP,MOLEX,JST.KYO,HRS等国际品牌，品种齐全，价格实惠。兼营各类电感器TAIYO,TOKO,NEC,PULSE,TDK,ALLIED等知名品牌。KNOWLES楼氏麦克风兼售。欢迎广大客户来电咨询。
QQ308923666　　
MSN:betoken816@msn.cn

货物价格仅供参考。
需要货物请旺旺联系。谢谢合作。

广东省内三通10元起，顺风以及EMS 速尔12起，广东省外三通14元起顺风及速尔24起偏远地区以及快递不到之处敬请买家事先说明，因为站点问题责任由买家自负。支持联邦等大宗货物物流公司，谢谢合作。
