无锡固电ISC 供应BU912三极管
信息内容：DESCRIPTION ·Collector-Emitter Sustaining Voltage-: VCEO(SUS)= 450V(Min)·High Switching Speed APPLICATIONS·Designed for applications such as electronic ignition, DCand AC motor controls, solenoid drivers,etc. ABSOLUTE MAXIMUM RATINGS(Ta=25℃)SYMBOLPARAMETERVALUEUNITVCBOCollector-Base Voltage 500VVCEOCollector-Emitter Voltage 450VVEBOEmitter-Base Voltage5VICCollector Current-Continuous6AICMCollector Current-Peak10AIBBase Current1APCCollector Power Dissipation@ TC=25℃60WTJJunctionTemperature150℃TstgStorageTemperature Range-65~150℃ THERMAL CHARACTERISTICSSYMBOLPARAMETERMAXUNITRth j-cThermal Resistance, Junction to Case2.08℃/W ELECTRICAL CHARACTERISTICSTC=25℃unless otherwise specifiedSYMBOLPARAMETERCONDITIONSMINTYP.MAXUNITVCEO(SUS)Collector-Emitter Sustaining VoltageIC= 100mA ;IB= 0450 VVCE(sat)-1Collector-Emitter Saturation VoltageIC= 2.5A; IB= 50mA 1.8VVCE(sat)-2Collecto...
无锡固电ISC 供应2N6609三极管
信息内容：DESCRIPTION ·Excellent Safe Operating Area·HighDC Current Gain-hFE=15(Min)@IC= -8A·Low Saturation Voltage-: VCE(sat)= -1.4V(Max)@ IC= -8A·Complement to Type 2N3773 APPLICATIONS·Designed for high power audio ,disk head positioners andother linear applications, which can also be used in powerswitching circuits such as relay or solenoid drivers, DC-DCconverters or inverters. ABSOLUTE MAXIMUM RATINGS(Ta=25℃)SYMBOLPARAMETERVALUEUNITVCBOCollector-Base Voltage-160VVCEXCollector-Emitter Voltage-160VVCEOCollector-Emitter Voltage-140VVEBOEmitter-Base Voltage-7VICCollector Current-Continuous-16AICPCollector Current-Peak-30AIBBase Current-Continuous-4AIBPBase Current-Peak-15APCCollector Power Dissipation @TC=25℃150WTJJunction Temperature200℃TstgStorage Temperature-65~200℃ ELECTRICAL CHARACTERISTICSTC=25℃unless otherwise specifiedSYMBOLPARAMETERCONDITIONSMINMAXUNITVCEO(SUS)Collector-Emitter Sustaining VoltageIC=...
