功率型厚膜贴片电阻
| 价 格： | 面议 | |
| 型号/规格： | 0603 | |
| 品牌/商标： | SUPEROHM(美隆) | |
| 环保类别： | 无铅环保型 |
功率型厚膜贴片电阻应用程序（应用）
◆电器：空调，冰箱（冷气机电子电路控制板及电冰箱）
◆汽车及工业用电器产品（汽车及工业用电子产品）
◆电脑及相关产品：主板，PDA（电脑及相关产品：主板，PDA）
◆通讯设备：手机，传真机（通讯设备：手机，传真机）
◆电源设备：电源，照明设备（电力设备：电源，照明设备）
◆娱乐：立体声，电视调谐器，磁带录像机（娱乐：立体音响，电视选配器，录音器）
◆测量仪器：电仪表，导航设备（测量工具：电子仪表，导航设备）
通用电气规格：
| Type | Size | Rated Power | Maximum Voltage | Resistance | Tolerance | T.C.R. | ||
| at 70℃ | Working | Overload | (Ω) | (ppm/℃) | ||||
| CRHP03 | 0603 | 0.125W | 50V | 100V | 1R - 9.9R | ±1%,±2%,±5%. | ±400 | |
| 10R~10M | ±0.1%,± 0.5%, ±1%,±2%,±5%. | ±100 | ||||||
| CRHP05 | 0805 | 0.25W | 150V | 300V | 1R - 9.9R | ±1%,±2%,±5%. | ±400 | |
| 10R~10M | ±0.1%,± 0.5%, ±1%,±2%,±5%. | ±100 | ||||||
| CRHP06 | 1206 | 0.5W | 200V | 400V | 1R - 9.9R | ±1%,±2%,±5%. | ±400 | |
| 10R~10M | ±0.1%,± 0.5%, ±1%,±2%,±5%. | ±100 | ||||||
| CRHP10 | 1210 | 0.66W | 200V | 400V | 1R - 9.9R | ±1%,±2%,±5%. | ±400 | |
| 10R~10M | ±0.1%,± 0.5%, ±1%,±2%,±5%. | ±100 | ||||||
| CRHP12 | 1812 | 1W | 200V | 400V | 1R - 9.9R | ±1%,±2%,±5%. | ±400 | |
| 10R~10M | ±0.1%,± 0.5%, ±1%,±2%,±5%. | ±100 | ||||||
| CRHP20 | 2010 | 1W | 200V | 400V | 1R - 9.9R | ±1%,±2%,±5%. | ±400 | |
| 10R~10M | ±0.1%,± 0.5%, ±1%,±2%,±5%. | ±100 | ||||||
| CRHP28 | 1218 | 2W | 200V | 400V | 1R - 9.9R | ±1%,±2%,±5%. | ±400 | |
| 10R~10M | ±0.1%,± 0.5%, ±1%,±2%,±5%. | ±100 | ||||||
| CRHP25 | 2512 | 2W | 200V | 400V | 1R - 9.9R | ±1%,±2%,±5%. | ±400 | |
| 10R~10M | ±0.1%,± 0.5%, ±1%,±2%,±5%. | ±100 | ||||||
| CRHP30 | 2030 | 3W | 200V | 400V | 1R - 9.9R | ±1%,±2%,±5%. | ±400 | |
| 10R~10M | ±0.1%,± 0.5%, ±1%,±2%,±5%. | ±100 | ||||||
| Operating Temperature Range: | -55℃ ~ 155℃ | |||||||
