供应应急充电器IC/HX3242-AP
| 价 格： | 面议 | |
| 型号/规格： | HX3242 | |
| 品牌/商标： | HX |
|
VIN/VOUT(min.)(V) |
VIN/VOUT(max.)(V) |
IQ (typ.)(uA) |
IOUT (max.)(mA) |
Package Type | |||||||||
| HX3001 |
0.9/2.5 |
4.4/5 | 260 | 800 | SOT-23-6 | |||||||||
| HX3003 |
0.9/3 |
4.4/3 | 300 | 800 | SOT-23-6 | |||||||||
| HX3005 |
0.9/2.5 |
4.4/5 | 250 | 800 | DFN2*2-6 | |||||||||
| HX3006 |
1.1/2.5 |
4.4/5 | 300 | 800 | DFN2*2-6 | |||||||||
| HX3021 |
0.9/2.5 |
4.4/5 | 20 | 700 | SOT-89-3 | |||||||||
|
HX3022 |
0.9/2.5 |
5/5.5 | 30 | 700 | SOT-23-6 | |||||||||
| HX3023 |
0.9/2.5 |
5/5.5 | 200 | 2500 | SOT-23-6 | |||||||||
| HX3031 |
0.9/3.3 |
3/3.3 | 30 | 700 | SOT-23-3 | |||||||||
| HX3042 |
2/2.4 |
5.5/20 | 40 | 3000 | DFN2*2-6 | |||||||||
| HX3141 |
0.9/1.8 |
5.5/5.5 | 70 | 3000 | SOT-23-6 | |||||||||
| HX3142 |
2.4/2.4 |
5.5/20 | 40 | 3000 | SOT-23-6 | |||||||||
| HX3242 |
2.4/2.4 |
5.5/20 | 40 | 3000 | SOP-8 | |||||||||
深圳市润芯微电子有限公司
联系人：赵小姐
联系电话：0755-33100277
手机：13530255775
QQ：1310658007
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 赵小姐/常先生/李小姐/陈小姐
- 电话：0755-33100277
- 传真：0755-33100277
- 手机：13530255775
- QQ ：
供应电压检测IC KX9006原装现货，价格
信息内容：High-precision detection Voltage： ±2% • Detection Voltage：0.9V~6.0V (in 0.1V steps) • Precise hysteresis：4% typ. • Operating Voltage range：0.7V~10V • Ultra-low current consumption：500nA typ. (at VDD＝3.0V)\ • Two Output Forms ：CMOS(Active Low) and N-channel open-drain(Active Low) 深圳市润芯微电子有限公司 联系人：赵小姐 联系电话：0755-33100277 手机：13530255775 QQ：1310658007
供应KX6000 500mA充电管理芯片
信息内容：FEATURES • Standalone Capability with no Requirement of External MOSFET, Sense Resistor or Blocking Diode. • Complete Linear Charger in Compact Package for Single Cell Lithium-Ion Batteries • Programmable Pre-charge, Fast Charge and Termination Current. • Constant-Current/Constant-Voltage Operation with Thermal Regulation to Maximize Charge Rate Without Risk of Overheating • Charges Single Cell Li-Ion Batteries Directly from USB Port • Preset 4.2V Charge Voltage with ±1% Accuracy • Automatic Recharge • Charge Status Output Pin • C/10 Charge Termination • 25µA Supply Current in Shutdown • 2.9V Trickle Charge Threshold • Soft-Start Limits Inrush Current • Available in 5-Lead SOT-23(0.5A) and ESOP8 Package(1A)
