SSR 单相交流控交流固态继电器

价格：

150.00


● SCR可控硅增强输出，过零点或者随机触发 ● 纯新件SMD贴装工艺，可靠性极高 ● DCB铜瓷键合基板，热循环次数高 ● IP20防护标准，LED工作状态指示 ● 内置RC吸收电路或压敏电阻器仰制突波发生
● SCR increased output, zero-crossing or random trigger ● The new piece of pure SMD mount technology, high reliability, ● DCB copper bonded ceramic substrates, the high number of thermal cycling ● IP20 standard of protection, LED working status indicator ● Built-in RC snubber or varistor surge occurred Yang System
◆型号说明

单相交流固态继电器	工作电压范围 Operating Voltage (47-63Hz): SSR23:24-280VAC,SSR48:42-530VAC,SSR60:42-660VAC
	峰值电压 Transient Overvoltage: 650Vp 1200Vp 1400Vp
	工作电流范围 Maximun Load Current: 150mA~25:25A, 50:50A, 75:75A, 100:100A 120:120A
	断态漏电流 Maximum Off-State Leakage Current: ≤3mA
	应答动作时间 Maximum Turn-On off Time: ON≤10mS, Off≤10mS
	绝缘电压 Dielectric Strength, Input/Output/Base:≥2500VAC 1Mni
	绝缘强度 Minimum Insulation Resistance: 500MΩ/500VDC
	工作温度 Ambient Operating Temperature Range: -20℃~+70℃
详细技术参数表:	点击PDF文件
