供应LEACH航天继电器M220

价格：		面议
型号/规格：		M220
品牌/商标：		LEACH

详细介绍
企业详情

APPLICATION NOTES:

APPLICABLE SOCKET:

Polarized, non latching hermetically sealed relay
Contact arrangement	4 PDT
Coil supply	Direct current
Qualified to	MIL-R-83536/5 and /6 CECC16101-028 CECC16303-804
PRINCIPLE TECHNICAL CHARACTERISTICS
Contacts rated at	5 Amps / 28 Vdc or 115 Vac - 400 Hz
Weight	27 grams max
Dimensions max. of case in mm	20.6 x 16.3 x 20.6
Hermetically sealed, corrosion resistant metal can.

CONTACT ELECTRICAL CHARACTERISTICS

Minimum
operating cycles

Contact rating per
pole and load type

Load Current in Amps

@28 Vdc

@115 Vac, 400 Hz

@115/200 Vac, 400 Hz 3?/b>

100,000 cycles
20,000 cycles
100,000 cycles
100,000 cycles

resistive load
inductive load (L/R=5ms)
motor load
lamp load

5
3
2
1

5
5
3
1

50 cycles

resistive overload

400,000 cycles

at 25% rated resistive load
