供应原装全新P+F传感器UC500-30GM-IUR2-V15现货
| 价 格： | 面议 | |
| 型号/规格： | UC500-30GM-IUR2-V15 | |
| 品牌/商标： | P+F（倍加福) |
UC500-30GM-IUR2-V15原装全新P+F传感器
原装，现货库存，底价销售
Ultrasonic sensor
UC500-30GM-IU-V1-HA
dzsc/18/6828/18682846.jpg
客服信息
- 联系客服
- Parameterization interface for the application-specific adjustment of the sensor setting via the service program ULTRA 3000
- Analog current and voltage output
- Adjustable acoustic power and sensitivity
- Temperature compensation
- UL and CSA NRTL certified for Class 1 Div 2 environments
帮助
Datasheet as PDF in following languages:
ENG
FRA
DEU
SPA
Technical Data: UC500-30GM-IU-V1-HA
| 产品阐述 | ||
| Single head system | ||
| General specifications | ||
| Sensing range | 30 ... 500 mm | |
| Adjustment range | 50 ... 500 mm | |
| Unusable area | 0 ... 30 mm | |
| Standard target plate | 100 mm x 100 mm | |
| Transducer frequency | approx. 380 kHz | |
| Response delay |
21 ms minimum 63 ms factory setting |
|
| Indicators/operating means | ||
| LED green |
solid: Power-on flashing: Standby mode or program function object detected |
|
| LED yellow 1 |
solid: object in evaluation range flashing: program function |
|
| LED yellow 2 |
solid: object in detection range flashing: program function |
|
| LED red |
solid: temperature/program plug not connected flashing: fault or program function object not detected |
|
| Temperature/TEACH-IN connector | Temperature compensation , Evaluation range programming , output function setting | |
| Electrical specifications | ||
| Operating voltage | 10 ... 30 V DC , ripple 10 %SS | |
| Power consumption | ≤ 900 mW | |
| Interface | ||
| Interface type | RS 232, 9600 Bit/s , no parity, 8 data bits, 1 stop bit | |
| Input/Output | ||
| Synchronization frequency | ||
| Common mode operation | max. 95 Hz | |
| Multiplex operation | ≤ 95/n Hz, n = number of sensors | |
| Output | ||
| Output type |
1 current output 4 ... 20 mA 1 voltage output 0 ... 10 V |
|
| Resolution | evaluation range [mm]/4000, but ≥ 0.05 mm | |
| Deviation of the characteristic curve | ≤ 0.2 % of full-scale value | |
| Repeat accuracy | ≤ 0.1 % of full-scale value | |
| Load impedance |
current output: ≤ 500 Ohm Voltage output: ≥ 1000 Ohm |
|
| Temperature influence |
≤ 2 % from full-scale value (with temperature compensation) ≤ 0.2 %/K (without temperature compensation) |
|
| Standard conformity | ||
| Standards | EN 60947-5-2 | |
| Approvals and certificates | ||
| UL approval | Class I Div 2 hazardous areas | |
| CSA approval |
NRTL certified Class I Div 2 hazardous areas |
|
| Ambient conditions | ||
| Ambient temperature | -25 ... 70 °C (-13 ... 158 °F) | |
| Storage temperature | -40 ... 85 °C (-40 ... 185 °F) | |
| Mechanical specifications | ||
| Connection type | Cable connector , M12 x 1 , 5-pin , 4-wire | |
| Protection degree | IP65 | |
| Connection | Cable connector , M12 x 1 , 5-pin , 4-wire | |
| Material | ||
| Housing |
1.4303 stainless steel plastic parts PBT |
|
| Transducer | epoxy resin/hollow glass sphere mixture; polyurethane foam | |
| Mass | 391 g | |
| Note | Individual components: UC-500-30GM-IUR2-V15; V1-G-2M-PVC; ADAPT-ALUM*-M30X1/2" NPT/HB | |
