供应全系列SOD-123FL封装二极管
| 价 格： | 150.00 | |
| 型号/规格： | SOD4007/DSR1M/S07M/SM4007PL/SOD1A7 | |
| 品牌/商标： | MDD | |
| 封装形式： | SOD-123FL | |
| 环保类别： | 无铅环保型 | |
| 安装方式： | 贴片式 | |
| 包装方式： | 卷带编带包装 | |
| 功率特性： | 超大功率 | |
| 频率特性： | 超高频 | |
| 整流电流： | 1A | |
| 反向击穿电流： | 1000V |
| Type | VRRM | I(AV) | IFSM | VF@IF | IR | Trr | Package | |
| V | A | A | V | A | μA | ns | ||
| DSR0.3A | 50 | 0.3 | 10 | 1.1 | 0.3 | 5 | - | SOD-123FL |
| DSR0.3B | 100 | 0.3 | 10 | 1.1 | 0.3 | 5 | - | SOD-123FL |
| DSR0.3D | 200 | 0.3 | 10 | 1.1 | 0.3 | 5 | - | SOD-123FL |
| DSR0.3G | 400 | 0.3 | 10 | 1.1 | 0.3 | 5 | - | SOD-123FL |
| DSR0.3J | 600 | 0.3 | 10 | 1.1 | 0.3 | 5 | - | SOD-123FL |
| DSR0.3K | 800 | 0.3 | 10 | 1.1 | 0.3 | 5 | - | SOD-123FL |
| DSR0.3M | 1000 | 0.3 | 10 | 1.1 | 0.3 | 5 | - | SOD-123FL |
| DSR0.5A | 50 | 0.5 | 15 | 1.1 | 0.5 | 5 | - | SOD-123FL |
| DSR0.5B | 100 | 0.5 | 15 | 1.1 | 0.5 | 5 | - | SOD-123FL |
| DSR0.5D | 200 | 0.5 | 15 | 1.1 | 0.5 | 5 | - | SOD-123FL |
| DSR0.5G | 400 | 0.5 | 15 | 1.1 | 0.5 | 5 | - | SOD-123FL |
| DSR0.5J | 600 | 0.5 | 15 | 1.1 | 0.5 | 5 | - | SOD-123FL |
| DSR0.5K | 800 | 0.5 | 15 | 1.1 | 0.5 | 5 | - | SOD-123FL |
| DSR0.5M | 1000 | 0.5 | 15 | 1.1 | 0.5 | 5 | - | SOD-123FL |
| S07A | 50 | 0.7 | 25 | 1.1 | 0.7 | 5 | - | SOD-123FL |
| S07B | 100 | 0.7 | 25 | 1.1 | 0.7 | 5 | - | SOD-123FL |
| S07D | 200 | 0.7 | 25 | 1.1 | 0.7 | 5 | - | SOD-123FL |
| S07G | 400 | 0.7 | 25 | 1.1 | 0.7 | 5 | - | SOD-123FL |
| S07J | 600 | 0.7 | 25 | 1.1 | 0.7 | 5 | - | SOD-123FL |
| S07K | 800 | 0.7 | 25 | 1.1 | 0.7 | 5 | - | SOD-123FL |
| S07M | 1000 | 0.7 | 25 | 1.1 | 0.7 | 5 | - | SOD-123FL |
| DSR1A | 50 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| DSR1B | 100 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| DSR1D | 200 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| DSR1G | 400 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| DSR1J | 600 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| DSR1K | 800 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| DSR1M | 1000 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| SOD4001 | 50 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| SOD4002 | 100 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| SOD4003 | 200 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| SOD4004 | 400 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| SOD4005 | 600 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| SOD4006 | 800 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| SOD4007 | 1000 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| SM4001PL | 50 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| SM4002PL | 100 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| SM4003PL | 200 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| SM4004PL | 400 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| SM4005PL | 600 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| SM4006PL | 800 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| SM4007PL | 1000 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| FM4001-M | 50 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| FM4002-M | 100 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| FM4003-M | 200 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| FM4004-M | 400 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| FM4005-M | 600 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| FM4006-M | 800 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
| FM4007-M | 1000 | 1 | 25 | 1.1 | 1 | 5 | - | SOD-123FL |
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 马先生
- 电话：0755-83041622/83041722
- 传真：0755-82727133
- 手机：15112288844
- QQ ：
特价供应 LED驱动电源专用超薄小体积二极管(图)
信息内容：深圳辰达行电子有限公司，是一家代理销售"MDD"品牌和推广品牌电子元器件的分销商，有着雄厚的经济实力和最直接的原厂进货渠道，具备品质保证﹑价格优良﹑供货快捷等特点，欢迎广大客户的来电来人咨询、订购！ 一般整流二极管 GENERAL PURPOSE RECTIFIERS型号反向峰值电压平均正向电流正向浪涌电流反向电 流正向电 压外型尺寸TypeMaximumPeakReverseVoltageMaximum AverageRectified Current@Half-WaveResistive Load 60HzMaximumForward PeakSurge Current@8.3ms SuperimposedMaximumReverseCurrent@PRV@25℃TAMaximumForwardVoltage@25℃TAPackageDimensionsPRVIo @ TAIFM(Surge)IRIFMVFMVPKAAV℃APKuAdcAPKVPK1N4001(G)501.075305.01.01.1DO-411N4002(G)1001.075305.01.01.11N4003(G)2001.075305.01.01.11N4004(G)4001.075305.01.01.11N4005(G)6001.075305.01.01.11N4006(G)8001.075305.01.01.11N4007(G)10001.075305.01.01.1 营业地址:深圳福田振华路鼎诚国际大厦1504 :深圳市福田区中航路都会电子城1C017电话:(86-755)82727166 82727366 传真:(86-755)82727133 企业QQ：800001677网址：http://www.szchenda.com
小信号开关二极管1SS187
信息内容：深圳辰达行电子有限公司，是一家代理销售"MDD"品牌和推广品牌电子元器件的分销商，有着雄厚的经济实力和最直接的原厂进货渠道，具备品质保证﹑价格优良﹑供货快捷等特点，欢迎广大客户的来电来人咨询、订购！ 产品主要封装外形有：SMA/DO-214AC、SMB/DO-214AA、SMC/DO-214AB、SOD-123、SOD-123FL、SOD-323、SOD-523、SOT-23、R-1、A-405、DO-41、DO-15、DO-27、R-3、R-6、TO-220、MB-S、MB-M、MBF、CDS、DB-1、DB-S、WOM、KBP、KBL、KBU、GBL、KBJ、GBJ、KBPC等...产品广泛应用于移动通信、计算机、消费类电子信息产品、家用电器、工业自动化控制设备等。 营业地址:深圳福田振华路鼎诚国际大厦1504 :深圳市福田区中航路都会电子城1C017电话:(86-755)82727166 82727366 传真:(86-755)82727133 企业QQ：800001677
