供应AVX贴片钽电容 TAJC156K035R
| 价 格： | 面议 | |
| 型号/规格： | TAJC156K035R | |
| 品牌/商标： | AVX | |
| 环保类别： | 无铅环保型 | |
| 安装方式： | 贴片式 | |
| 包装方式： | 卷带编带包装 | |
| 产品主要用途： | 家用电器 | |
| 引出线类型： | | |
| 特征： | | |
| 标称容量范围： | 15uf | |
| 额定电压范围： | 35V | |
| 温度系数范围： | ℃ |
CAPACITOR, CASE C, 15UF, 35V
Capacitance: 15µF
Capacitance Tolerance: ± 10%
Voltage Rating: 35V
ESR: 1.4ohm
Capacitor Case Style: 2312
Operating Temperature Range: -55°C to +125°C
SVHC: No SVHC (19-Dec-2011)
Capacitor Mounting: SMD
External Depth: 2.6mm
External Length / Height: 6.00mm
External Width: 3.20mm
Leakage Current: 5.3µA
No. of Pins: 2
Operating Temperature Max: 125°C
Operating Temperature Min: -55°C
Package / Case: C
Terminal Type: Surface Mount (SMD, SMT)
Termination Type: SMD
Tolerance +: 10%
Tolerance -: 10%
Voltage Rating V DC: 35V
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 范小姐
- 电话：0755-82565286
- 传真：0755-82565296
- 手机：13760297764
- QQ ：
供应贴片AVX钽电容 TAJE106K035R
信息内容：CAPACITOR, CASE E, 10 UF, 35V Capacitance: 10µF Capacitance Tolerance: ± 10% Voltage Rating: 35V ESR: 0.9ohm Capacitor Case Style: 2917 Operating Temperature Range: -55°C to +125°C SVHC: No SVHC (19-Dec-2011) Capacitor Mounting: SMD Leakage Current: 11.6µA No. of Pins: 2 Package / Case: E Termination Type: SMD
供应AVX贴片钽电容 TAJD106K035R D型
信息内容：CAPACITOR, 10UF, 35V, REEL 500 Capacitance: 10µF Capacitance Tolerance: ± 10% Voltage Rating: 35V ESR: 1ohm Capacitor Case Style: 2917 Operating Temperature Range: -55°C to +85°C SVHC: No SVHC (19-Dec-2011) Capacitor Mounting: SMD ESR Frequency: 100kHz ESR Temperature: 25°C External Depth: 2.9mm External Length / Height: 7.3mm External Width: 4.3mm Leakage Current: 3.5µA No. of Pins: 2 Operating Temperature Max: 85°C Operating Temperature Min: -55°C Package / Case: D Packaging Type: Reel Reel Quantity: 500 Tape Width: 12mm Terminal Type: Surface Mount (SMD, SMT) Termination Type: SMD Tolerance +: 10% Tolerance -: 10% Voltage Rating V DC: 35V
