供应AVX贴片钽电容 TAJE476K035R E型 47U
| 价 格： | 面议 | |
| 型号/规格： | TAJE476K035R | |
| 品牌/商标： | AVX | |
| 环保类别： | 无铅环保型 | |
| 安装方式： | 贴片式 | |
| 包装方式： | 卷带编带包装 | |
| 产品主要用途： | | |
| 引出线类型： | | |
| 特征： | | |
| 标称容量范围： | 47uf | |
| 额定电压范围： | 35V | |
| 温度系数范围： | ℃ |
CAPACITOR, CASE E, 47UF, 35V
Capacitance: 47µF
Capacitance Tolerance: ± 10%
Voltage Rating: 35V
ESR: 0.9ohm
Operating Temperature Range: -55°C to +125°C
SVHC: No SVHC (19-Dec-2011)
Capacitor Mounting: SMD
External Depth: 4.1mm
External Length / Height: 7.3mm
External Width: 4.3mm
Leakage Current: 16.5µA
No. of Pins: 2
Operating Temperature Max: 125°C
Operating Temperature Min: -55°C
Package / Case: E
Reel Quantity: 400
Tape Width: 8mm
Terminal Type: Surface Mount (SMD, SMT)
Termination Type: SMD
Tolerance +: 10%
Tolerance -: 10%
Voltage Rating V DC: 35V
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 范小姐
- 电话：0755-82565286
- 传真：0755-82565296
- 手机：13760297764
- QQ ：
供应贴片钽电容AVX TAJV336K035R
信息内容：CAPACITOR, CASE V, 33 UF, 35V Capacitance: 33µF Capacitance Tolerance: ± 10% Voltage Rating: 35V ESR: 0.5ohm Capacitor Case Style: 2924 Operating Temperature Range: -55°C to +125°C SVHC: No SVHC (19-Dec-2011) Capacitor Mounting: SMD No. of Pins: 2 Package / Case: V Termination Type: SMD
供应AVX钽电容 TAJE336K035R E型
信息内容：CAPACITOR, CASE E, 33UF, 35V Capacitance: 33µF Capacitance Tolerance: ± 10% Voltage Rating: 35V ESR: 0.5ohm Operating Temperature Range: -55°C to +125°C SVHC: No SVHC (19-Dec-2011) Capacitor Mounting: SMD External Depth: 4.1mm External Length / Height: 7.30mm External Width: 4.30mm Leakage Current: 11.6µA No. of Pins: 2 Operating Temperature Max: 125°C Operating Temperature Min: -55°C Package / Case: E Terminal Type: Surface Mount (SMD, SMT) Termination Type: SMD Tolerance +: 10% Tolerance -: 10% Voltage Rating V DC: 35V
