供应单相共模电源线滤波器
| 价 格： | 面议 | |
| 型号/规格： | AC250V6A-Y20K003A | |
| 品牌/商标： | 科力亚特 | |
| 环保类别： | 普通型 | |
| 安装方式： | 螺栓式 | |
| 主要用途： | |
产品特点
Features
差模（共模）增强型，优异的低频衰减特性
More excellent with differential（common） mode choke,
very high performance for low frequency niose
High performance/cost ratio
2.可按不同性能、工作电流、电压、外形尺寸和端接方式等要求定制。
Customization design for different requirements such as p erformance,rated current,rated voltage, shape dimension and termination methods.
适用场合
Application
1.用于各种开关逆变类变换器。（差模）
For switching power supplies and converters（Differential）
2.用于各种对噪声抑制需要较高的电子设备，可抑制连续或间隙性脉冲干扰。（共模）
For electronic equipments with high performance requirement for noise attenuation toSuppress the continuity or intermittent pulse interference.（Common）
技术参数
Technical Data
|
额定电压 Rated Voltage |
250VAC |
|||||||
|
工作频率 Operating Frequency |
50/60Hz |
|||||||
|
耐 电 压 Withstanding voltage |
线—线 Line to line |
1450VDC |
1min |
|||||
|
线—地 Line to ground |
1500VAC |
1min |
||||||
|
温度范围 temperature range |
-25--+85 |
|||||||
|
单相差模增强系列型号 |
||||||||
|
型号 |
额定电流 |
电路类型 |
外形尺寸 |
端接方式 |
漏电流 |
|||
|
DC-2A |
2 |
1 |
1 |
电源线 |
0.3 |
|||
|
DC-3A |
3 |
1 |
1 |
电源线 |
0.3 |
|||
|
DC-3A21W |
3 |
2 |
1 |
电源线 |
0.3 |
|||
|
DC-6A |
6 |
1 |
2 |
焊片 |
0.5 |
|||
|
DC-6A22L |
6 |
2 |
2 |
焊片 |
0.5 |
|||
|
DC-10A |
10 |
1 |
3 |
螺栓 |
0.5 |
|||
|
DC-20A |
20 |
1 |
3 |
螺栓 |
0.5 |
|||
|
DC-20A23S |
20 |
2 |
3 |
螺栓 |
0.5 |
|||
|
DC-30A |
30 |
1 |
4 |
螺栓 |
0.5 |
|||
|
DC-30A24S |
30 |
2 |
4 |
螺栓 |
0.5 |
|||
|
单相共模增强系列型号 |
||||||||
|
型号 |
额定电流 |
电路类型 |
外形尺寸 |
端接方式 |
漏电流 |
|||
|
DG-1A |
3 |
1 |
1 |
电源线 |
0.3 |
|||
|
DG-3A |
3 |
1 |
1 |
电源线 |
0.3 |
|||
|
DG-6A |
6 |
1 |
2 |
焊片 |
0.3 |
|||
|
DG-10A |
10 |
1 |
2 |
焊片 |
0.5 |
|||
|
DG-20A |
20 |
1 |
3 |
螺栓 |
0.5 |
|||
|
DG-30A |
30 |
1 |
|
螺栓 |
0.5 |
|||
|
DG-50A |
30 |
1 |
|
螺栓 |
0.5 |
|||
|
DG-100A |
30 |
1 |
4 |
螺栓 |
0.5 |
|||
