1. YCCA-II Technical data:
技术参数 Technical Data |
单位 Unit |
YCCA-II |
额定载荷Emax(Rated Capacity) |
t |
10,20,25,30 |
t |
40,50 |
|
额定输出(Rated Output) |
mV/V |
2.0 |
零点平衡(Zero Balance) |
mV/V |
0±0.1 |
温度对灵敏度影响(Temperature Effect On Output) |
%/10K |
±0.02 |
温度对零点影响(Temperature Effect On Zero) |
%/10K |
±0.02 |
非线性误差(Non-Linearity) |
% |
±0.03 |
滞后误差(Hysteresis Error) |
% |
±0.03 |
蠕变及蠕变恢复(Creep/30 Min) |
% |
±0.02 |
输入电阻(Input Resistance) |
Ω |
352±3 |
输出电阻(Output Resistance) |
Ω |
350±3 |
参考电压(Reference Excitation Voltage) |
V |
5 |
工作电压(Maximum Excitation Voltage) |
V |
15 |
绝缘电阻(Insulation Resistance) |
GΩ/100V |
>2 |
额定温度范围(Nominal Temperature Range) |
℃ |
-10~+40 |
工作温度范围(Operating Temperature Range) |
℃ |
-30~+70 |
储存温度范围(Storage Temperature Range) |
℃ |
-30~+70 |
安全承载(Safe Load Limit) |
% |
150 |
极限承载(Breaking Load) |
% |
200 |
材料(Material) |
|
Stainless steel |
保护等级 (Protection class) |
|
IP68 |
