供应HRS FH12-**S-0.5S(H) FPC连接器

价格：		面议
型号/规格：		FH12-**S-0.5S(H)
品牌/商标：		Hirose / HRS（日本广濑）

详细介绍
企业详情

1.All information, such as connector specifications, dimensions, etc, on the web site are reference only. Connector information can be changed without notice.
Please request the latest specification and DWG from HRS before you design in our products.
Please confirm the RoHS status using the RoHS Compliant Part Number Search on this web site.
2.Please check the availability of Non-RoHS compliant products before ordering. Non-RoHS compliant products may be discontinued.

FH12 Series

dzsc/18/5740/18574058.jpg			-Features
			●	Only slight force is required to lock the flip-lock (one-touch rotating system) zero insertion force (ZIF) structure.
			●	The locking mechanism clicks, thus making it possible to confirm flexible printed circuit (FPC) and flexible flat cable (FFC) connections.
			●	One-touch zero insertion force (ZIF) structure reduces working space, thus making mounting possible in the center of the PCB.
			●	Upper, lower, and vertical contact types are available.
			●	1mm pitch type as well as 0.5mm pitch type are available.
dzsc/18/5740/18574058.gif	dzsc/18/5740/18574058.gif	dzsc/18/5740/18574058.gif	-Applications
		Photograph_Help	LCD, Mobile phones, CD-ROM, Portable equipment
dzsc/18/5740/18574058.gif	dzsc/18/5740/18574058.gif
	482KB

-SpecificationsHelp

Characteristic	Specifications
No. of Positions	4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 22, 24, 25, 26, 28, 29, 30, 32, 33, 34, 35, 36, 40, 42, 45, 49, 50, 53, 60
Current Rating(Amps)(Max.)	0.4
PCB Mount Type	SMT
Contact Mating Area Plating	Gold
Terminal Pitch (mm)	0.5, 1, 2
Contact Spacing (mm)	0.5, 1
Operating Temperature Range (degrees C)	-40 to 70, 85
FPC Thickness (mm)	0.12, 0.18, 0.3
Connector Type	Board mounting
Contact Gender	Female
Remarks	FPC/FFC connector
Mounted Height (mm)	2, 2.4, 4.85
