iqd温补晶振 温补压控晶振
| 价 格： | 面议 | |
| 型号/规格： | cfpt-125 | |
| 品牌/商标： | iqd | |
| 环保类别： | 无铅环保型 | |
| 安装方式： | 贴片式 | |
| 主要用途： | 工业电子电气设备 |
| 11x9mm | 9.6~40.0MHz | 3.0V | ±2.5~±5ppm | -30~+75℃ | clipped Sine | 带压控或机械调整 | |
| CFPT-123 | 7x5mm | 10~26.0MHz | 3.0V | ±1.5~±5ppm | -40~+85℃ | clipped Sine | 宽温，压控调整 |
| CFPT-125 | 7x5mm | 10~40.0MHz | 3.3V | ±0.9ppm | -20~+70℃ | HCMOS | 压控调整，高稳定性，性价比高 |
| CFPT-126 | 7x5mm | 10~40.0MHz | 3.3V | ±0.5ppm | -40~+85℃ | HCMOS | 宽温，搞稳定性，压控调整 |
| CFPT-127 | 5x3mm | 10~40.0MHz | 3.0V | ±0.5ppm | -40~+85℃ | clipped Sine | 微封装性，宽温，高稳定性，适合GPS应用 |
| CFPT-141 | 5x3mm | 10~30.0MHz | 3.0V | ±1.5~±5ppm | -40~+85℃ | clipped Sine | 微型封装，通常应用于狭小空间 |
| CFPT-37 | 7x5mm | 10~40.0MHz | 3.3V | ±0.9ppm | -20~+70℃ | HCMOS | 不带压控调整，性价比高 |
| CFPT-8000 | 20x13 | 13~160.0 | 5.0V | ±1~±3ppm | -30~+85℃ | HCMOS | 适合stratum或SONEFT应用 |
| mm | MHz | 3.3V | |||||
| CFPT-9003 | 7x5mm | 10~40.0MHz | 5.0V | ±0.3~±2.5ppm | -40~+85℃ | Sine | 高性能，低功耗，低相躁，高端应用，移动通信 |
| CFPT-9005 | 7x5mm | 10~40.0MHz | 5.0V | ±0.3~±2.5ppm | -40~+85℃ | clipped Sine | 高性能，低功耗，低相躁，高端应用移动通信 |
| CFPT-9007 | 7x5mm | 10~40.0MHz | 3.3V | ±0.3~±2.5ppm | -40~+85℃ | Sine | 高性能，低功耗，低相躁，高端应用，移动通信 |
| CFPT-9008 | 7x5mm | 10~40.0MHz | 3.3V | ±0.3~±2.5ppm | -40~+85℃ | clipped Sine | 高性能，低功耗，低相躁，高端应用，移动通信 |
| CFPT-9051 | 14x9mm | 1~50.0MHz | 5.0V | ±0.3~±2.5ppm | -55~+105℃ | HCMOS | 高性能，宽温，低功耗，低相躁，应用广泛 |
| CFPT-9053 | 14x9mm | 8~50.0MHz | 5.0V | ±0.3~±2.5ppm | -55~+105℃ | Sine | 高性能，宽温，低功耗，低相躁，应用广泛 |
| CFPT-9055 | 14x9mm | 1~80.0MHz | 5.0V | ±0.3~±2.5ppm | -55~+105℃ | HCMOS | 高性能，宽温，低功耗，低相躁，应用广泛 |
| CFPT-9057 | 14x9mm | 8~50.0MHz | 5.0V | ±0.3~±2.5ppm | -55~+105℃ | clipped Sine | 高性能，宽温，低功耗，低相躁，应用广泛 |
| CFPT-9058 | 14x9mm | 1~50.0MHz | 3.3V | ±0.3~±2.5ppm | -55~+105℃ | HCMOS | 高性能，宽温，低功耗，低相躁，应用广泛 |
| CFPT-9059 | 14x9mm | 8~50.0MHz | 3.3V | ±0.3~±2.5ppm | -55~+105℃ | Sine | 高性能，宽温，低功耗，低相躁，应用广泛 |
| CFPT-9060 | 14x9mm | 1~80.0MHz | 3.3V | ±0.3~±2.5ppm | -55~+105℃ | HCMOS | 高性能，宽温，低功耗，低相躁，应用广泛 |
| CFPT-9061 | 14x9mm | 8~50.0MHz | 3.3V | ±0.3~±2.5ppm | -55~+105℃ | clipped Sine | 高性能，宽温，低功耗，低相躁，应用广泛 |
| CFPT-9400 | 14x9mm | 6xx.xxxxMHz | 3.3V | ±20ppm | 0~+85℃ | LVPECL | 超高频TCVCXO |
| Overall | |||||||
| CFPT-9301 | 5x3mm | 1~52.0MHz | 3.3V | ±0.2~±2ppm | -40~+85℃ | HCMOS | 微型高精度TCVCXO，高稳定性，低功耗和相躁 |
| CFPT-9302 | 5x3mm | 12~52.0MHz | 3.0V | ±0.2~±2ppm | -40~+85℃ | clipped | 微型高精度TCVCXO，高稳定性，低功耗和相躁 |
| Sine | |||||||
| CFPT-9025 | 9.3x7.6 mm | 1~50.0MHz | 5.0/ | ±0.3~±2.5ppm | -55~+125℃ | Sine | 军级温度，加速度20000G，高稳定性，适用于军工及GPS导航系统等 |
| 3.3V | HCMOS | ||||||
| CFPT-69 | 2.2x2mm | 13~38.4MHz | 3.0V | ±0.5,±2ppm | -30~+85℃ | clipped | 主要应用于GPS, GPRS, GSM, Wi-Fi 和 WiMax等 |
| Sine | |||||||
| CFPT-75 | 3.2x2.5mm | 13~38.4MHz | 3.0V | ±0.5,±2ppm | -30~+85℃ | clipped | 主要应用于GPS, GPRS, GSM, Wi-Fi 和 WiMax等 |
| Sine | |||||||
| CFPT-77 | 2.5x2mm | 13~38.4MHz | 1.8V | ±0.5,±2ppm | -30~+85℃ | clipped | 主要应用于GPS, GPRS, GSM, Wi-Fi 和 WiMax等 |
| Sine |
