芯片概述

   DM114是专为LED显示应用所设计的横流驱动芯片。8个输出通道的电流可由一外挂电

阻调整。内建8比特移位缓存器，数据锁存器，以及横流电路组件于硅CMOS芯片上。

芯片特色

●          输出承受电压：17V

●          时钟频率：25MHZ(级联操作)

●          芯片工作电压：3.3V-5.0V

●          COMS兼容输入

●          封装形式：PDIP16, SOP16, SSOP16

●          封装及管脚定义与通用16脚LED横流驱动器ST2221A完全兼容（每个特征值不同）

●          恒流性：（TA=25℃`VDD=5.0V）

芯片间输出电流差异值：Chip-to Chip:±10.0%

                                      Bit-to-Bit:±4.0% @ IOUT=30-90Ma

                                                 ±6.0%@IOUT=20-30Ma

 DM134 DM135 DM136

16-Bit constant current led drivers

General Description

     The DM134 DM135 DM136 are constant current drivers specifically designed for LED display applications. The value of constant current can be varied using an external resistor. The devices include a 16-bit shift Register, latches, and constant current drivers on a single silicon CMOS chip.

Features

●          5V CMOS Compatible Input

●          Maximum Clock frequency: 25MHZ(Cascade Operation)

●          Maximum Output Voltage: 17v

●          Package:                DIP24, SOP24, SSOP24, QFN32,

                             TSSOP24-exposedPAD(DM135)

●          Package and pin layout:  Pin layout and functionality are similar to those of the ST2221C(Each characteristic value is different.)

●          Constant current matching（TA=25℃`VDD=5.0V）

                                Chip-to Chip:±10.0%

                      Bit-to-Bit:

                                     DM134:±4.0% @ IOUT=30-90MA

                                    ±6.0%@IOUT=20-30MA

                                      DM135:±4.0% @ IOUT=10-50Ma

                                             ±6.0%@IOUT=5-10mA

                                      DM136:±4.0% @ IOUT=3-15mA
