供应小型大功率继电器UDH-SS-124D

价格：		面议
型号/规格：		UDH-SS-124D,UDH-SS-112D
品牌/商标：		GOODSKY

详细介绍
企业详情

UDH
dzsc/18/5103/18510309.jpg
Outline (L x W x H)			22.0 x 16.8 x 14.5 mm
Weight			9.5 g
Features			UDH Relay Series is designed with switching capacity by 12A to comply with user’s selection. Insulation distance 4 mm Min. is designed. The employment of insulation material is meeting to JIS Insulation Class E. The Dielectric Strength of 2,000VAC Min. and Surge Resistance of 5,000V can be reached. 2.54 mm terminal pitch employment is equal to I.C.’s terminal pitch. Employment of suitable plastic materials is to be applied to high temperature condition and various chemical solutions. Complete protective construction is designed from dust and soldering flux. If required, the plastic sealed type is available for washing procedure.
Contact Specification
	Contact Form		SPST / SPDT
	Contact Rating		12A/120VAC 12A/24VDC
Coil Specification
	Coil Voltage	DC	3, 5, 6, 9, 12, 24, 48
		AC	----
	Power Consumption		0.45W
Dielectric Strength
	Between Coil & Contact (50/60 Hz for 1 minute)		AC 1,500V
	Between Contact (50/60 Hz for 1 minute)		AC 750V
Life Expectancy (Operations)
	Electrical		1 x 10⁵
	Mechanical		1 x 10⁷
Safety Standard			UL, C-UL
P.C.B Layout			dzsc/18/5103/18510309.jpg
Mounting Method			PC board terminal

深圳市福田区广辉电经营部

公司信息未核实

所属城市：广东深圳
[联系时请说明来自维库仪器仪表网]
联系人： 陈树辉
电话：0755-82534577/13076512089
传真：0755-82534577
手机：13686868407
QQ ：

公司相关产品

供应AC/DC电源模块YAW1015E

信息内容：

The YAW1015E AC100 V/200 V world wide input small AC-DC converter with resin case. The lineup includes 5 W-10 W/ dual output. Features: Universal input voltage (AC85 - 264V) P.C.board mount AC-DC converter Built-in inrush current and overcurrent protection circuits Small and compact size S.M.T. (Surface Mount Technology) implemented for smaller and lighter weight Safety agency approvals UL recognized, TV approved, CSA certified (External Fuse is required) CE marking Low Voltage Directive Environment RoHS directive EMI Complies with FCC-B, VCCI-B, CISPR22-B, EN55022-B, additional capacitor is required for meeting ISPR22-B, EN55022-B Product Highlight Type: Encapsulated No of Outputs: Dual Output Power: 10.5 W Output Voltage: 15 V / 30 V Input Voltage: 85 to 264 V dzsc/18/5103/18510310.jpg dzsc/18/5103/18510310.jpg dzsc/18/5103/18510310.jpg dzsc/18/5103/18510310.jpg

详细内容>>

供应A2-F温度保险丝115℃ 2A 250V

信息内容：

A-F系列型号额定动作温度实测动作温度保持温度极限温度额定电流额定电压安规认证 RoHS符合品 UL CUL VDE TUV PSE CCC EK A1-F 102℃ 98±2℃ 79℃ 203℃ 2A 250V ● ● ● ● ● ● ● ● A2-F 115℃ 112±3℃ 92℃ 203℃ 2A 250V ● ● ● ● ● ● ● ● A3-F 125℃ 120±3℃ 101℃ 203℃ 2A 250V ● ● ● ● ● ● ● ● A4-F 130℃ 126±2℃ 107℃ 203℃ 2A 250V ● ● ● ● ● ● ● ● A5-F 135℃ 131±3℃ 112℃ 203℃ 2A 250V ● ● ● ● ● ● ● ● A7-F 138℃ 135±2℃ 115℃ 203℃ 2A 250V ● ● ● ● ● ● ● ● A8-F 150℃ 145±3℃ 126℃ 203℃ 2A 250V ● ● ● ● ● ● ● ● dzsc/18/5103/18510311.jpg 额定动作温度(Tf)：温度保险丝按标准规定方法测试，改变其导电状态的温度。按基于IEC691的安全标准规定，温度保险丝必须在上述温度+0/-10℃范围内动作。(日本电气用品管理法规定公差范围为±7℃范围内动作）。实测动作温度：温度保险丝在硅油池内以每分钟0.5-...

详细内容>>
