供应日本北陆VG039NCHXTB302(3K)3X3可调电阻
| 价 格： | 0.18 | |
| 型号/规格： | VG039NCHXTB302(3K) | |
| 品牌/商标： | 日本北陆 | |
| 环保类别： | 无铅环保型 | |
| 产品主要用途： | 普通/民用电子信息产品 | |
| 功率分类： | 小功率（＜1W） | |
| 精度类别： | 普通型 | |
| 外形结构特征： | 圆盘型 | |
| 引出线类型： | 无引出线 | |
| 包装形式： | 盒带编带包装 |
日本北陆可调电阻 VG039NCHXTB系列
（咨询热线：15986814662 QQ：800009289
■Features
●3mm size,Low profile type ( 1.2mm in height )
●With rotation stopper
●Achieved excellent endurance characteristics by using“Metal-glaze”film
●Conform to RoHS Directives
●Reflow solderable
■Specification
Nominal Total Rasistance 100~1MΩ
Rasistance Tolerance ±25%
Rated Wattage 0.15W
T.C.R. ( Temperature Coefficient of Resistance ) ±250ppm/℃
Operating Temperature Range -40~100℃
Packaging Quantity 2,500pcs / Reel
■型号与规格：
VG039NCHXTB101 ( 100R )
VG039NCHXTB102 ( 1 K )
VG039NCHXTB103 ( 10K )
VG039NCHXTB104 ( 100K )
VG039NCHXTB105 ( 1M )
VG039NCHXTB201 ( 200R )
VG039NCHXTB202 ( 2K )
VG039NCHXTB203 ( 20K )
VG039NCHXTB204 ( 200K )
VG039NCHXTB301 ( 300R )
VG039NCHXTB302 ( 3K )
VG039NCHXTB303 ( 30K )
VG039NCHXTB501 ( 500R )
VG039NCHXTB502 ( 5K )
VG039NCHXTB503 ( 50K )
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 康娟
- 电话：0755-82544557
- 传真：0755-82544559
- 手机：13724370912
- QQ ：
