供应VTE18-4P8112,SICK光电开关
| 价 格： | 面议 | |
| 型号/规格： | VTE18-4P8112 | |
| 品牌/商标： | sick |
如有需求者请与 At a glance Your benefits
Model Name
VTE18-4P8112
Part No.
6013099
Standard photoelectric proximity sensor in M18 cylindrical housing
Energetic proximity sensor with three scanning distances of 200 m, 400 mm or 800 mm
3-wire technology
Axial or radial optics output
Standardized design enables simple assembly and alignment and simple replacement of the device
Individual devices for various scanning distances
Suitable for signal processing e.g. with AS-i coupling modules or M12 distributor islands
Flexibility in case of restricted installation space
Features
Sensing range max.:
10 mm ... 800 mm 1)
Sensing range:
10 mm ... 700 mm
Housing design (light emission):
straight
Light source:
LED 2)
Type of light:
Infrared light
Adjustment:
no/fix
Housing length:
63.6 mm
Thread diameter (housing):
M18 x 1
Sensor/detection principle:
Photoelectric proximity sensor, energetic
Light spot (distance):
40 mm (800 mm)
Optical axis:
Axial
1) Object with 90 % reflectance (referred to standard white DIN 5033) 2) Average service life 100,000 h at Ta = +25 °C
Mechanics/electronics
Enclosure rating:
IP 67
Supply voltage:
10 V DC ... 30 V DC 1)
Residual ripple:
≤ 10 % 2)
Power consumption:
≤ 30 mA 3)
Switching output:
PNP, light/dark-switching, Selectable via L/D control wire, open collector 4)
Output current Imax.:
100 mA
Response time:
≤ 2 ms 5)
Switching frequency:
250 Hz with light/dark ratio 1:1
Connection type:
Cable, 4-wire 2 m 6)
Cable material:
PVC
Conductor cross-section:
0.14 mm²
Cable diameter:
5 mm
Protection class:
III
Circuit protection:
A
B
C
D 7) 8) 9) 10)
Weight:
120 g
Housing material:
Nickel-plated brass
Optics material:
PMMA
Ambient operating temperature:
-25 °C ... 70 °C
Angle of dispersion:
2.8 °
1) Limit values 2) 3) Without load 4) Control wire open: dark-switching D.ON 5) Signal transit time with resistive load 6) Do not bend below 0 °C 7) A = VS connections reverse-polarity protected 8) B = inputs and output reverse-polarity protected 9) C = interference suppression 10) D = outputs overcurrent and short-circuit protected
- 所属城市：广东 佛山
- [联系时请说明来自维库仪器仪表网]
- 联系人： 彭丽
- 电话：0757-81810377
- 传真：0757-81810377
- 手机：18927211286
- QQ ：
