供应7mm高超小型无极性电解电容器2.2UF50V 4*7
| 价 格： | 面议 | |
| 型号/规格： | NPH7，2.2UF50V 4*7， 4.7UF50V 4*7 | |
| 品牌/商标： | micon | |
| 环保类别： | 无铅环保型 | |
| 安装方式： | 直插式 | |
| 包装方式： | 散装 | |
| 产品主要用途： | 家用电器 | |
| 引出线类别： | 径向引线型 | |
| 特征： | 圆柱体型 | |
| 标称容量范围： | 2.2uf | |
| 额定电压范围： | 50V | |
| 温度系数范围： | 105℃ |
NPH7 series Non-Polarized Miniaturized 7mm height 105℃超小型品
1. 本体之高度缩短至7m/m,适用于轻薄小型化之电子产品.
Developed short body length to 7m/m, for the demand of smaller and thinner electronic equipment.
2. 适用于极性反转回路，例如：信号交连或HI-FI音响设备如喇叭等。
NP series capacitors are suitable for crossover network for HI-FIequipment’s and speakers, etc.
3. 具容量误差小，频率响应高之特质。
Have excellent frequency characteristic and small deviation of Capacitance.
Specifications
|
No. |
Item |
Performance | ||||||||||||||||||||||||
|
1 |
使用温度范围 Operating Temperature Range |
-40℃ to +105℃ | ||||||||||||||||||||||||
|
2 |
定格电压范围 Rated Working Voltage Range |
6.3-63V.DC | ||||||||||||||||||||||||
|
3 |
静电容量范围 Capacitance Tolerance |
0.1－47µF | ||||||||||||||||||||||||
|
4 |
静电容量容许差 Capacitance Tolerance |
±20% (at+25℃,120Hz) | ||||||||||||||||||||||||
|
5 |
泄漏电流 Leakage Current |
I≤0.03CV or 3（µA） after five minutes | ||||||||||||||||||||||||
|
6 |
损失角 Dissipation Factor(tanδ) （120Hz\＋25℃） |
| ||||||||||||||||||||||||
|
7 |
温度特性（at 120 Hz） Characteristics at low temperature （stability at 120Hz） |
| ||||||||||||||||||||||||
|
8 |
高温负荷特性 High Temperature Loading |
After1000 hrs. application of DC rated working voltage at +105℃. The capacitor shall meet the following limits: Post test requirements at + 25℃
| ||||||||||||||||||||||||
|
9 |
高温无负荷特性 Shelf Life |
After storage for 500hrs. at+105℃ with no voltage applied. Post test requirements at+25℃ Same limits for high temperature lading. |
