HP/Agilent HP8590L 频谱分析仪

HP8590L频谱分析仪HP 8590L,惠普HP8590L带宽范围: 9KHz-1.8GHz ,参数值l–115-+30dbm，HP8590L所属品
牌:美国Agilent安捷伦HP惠普

描述
The Agilent 8590L is a low cost, but full-featured, frequency accurate RF spectrum analyzer
designed to meet your general purpose measurement needs. The easy-to-use interface provides
access to more than 200 built-in functions.
? Frequency counter: Eliminate the need for a separate frequency counter with the
built-in frequency counter-with ±2.1 kHz accuracy at 1 GHz (±7.6 kHz
 from 0 to 50 °C)
? Multiple resolution bandwidth filters: Optimize the tradeoffs of speed, sensitivity
 and the separation of closely spaced signals with your choice of 10 res
 olution bandwidth filters beginning at 1 kHz
? 145 dB amplitude measurement range: Measure signals directly with -115 dBm to +30 dBm
 amplitude measurement range
? One-button measurement routines: Save time, setup, and training with one button                                                                    measurement routines such as Adjacent Channel Power, sign                          al bandwidth and Third Order Intercept (TOI)
? Phase noise of 105 dBc/Hz at 30 kHz offset: Uncover small signals close to carriers
with an internal phase noise that will not get in your way
? Dual interfaces: Operate remotely and print directly with the optional dual interfaces
 that combine either an GP-IB or RS-232 port with a parallel (Centr                              onics) port
? Built-in tracking generator: Measure the scalar characteristics of your components
with the optional built-in tracking generator and the Agilent 85714A sca                            lar measurements personality
