| Front panel seal |
IP 65/NEMA 4 (indoor use only) |
| Memory RAM |
512 KB |
| Flash memory for application |
4 MB |
| Processor |
32-bit RISC |
| Real time clock |
Yes (rechargeable Lithium battery) |
| Display |
Color TFT LCD, 256 colors, 320 x 240 pixels,
CCFT backlight lifetime: approximately 60,000 h at 25 °C, Analog |
| Screen size |
5.7" (diagonal) |
| Active area of display, W x H |
117.2 x 88.4 mm
40 x 30 characters of 8 x 8 size can be displayed |
| Back light type |
LED |
| Brightness (cd/m2) |
350 |
| Back light life |
30,000 hours |
| Function keys |
1 Menu key and 5 user-defined function keys (F1—F5) |
| Operation status LED |
PWR, COM1, COM2, Ethernet LEDs |
| Touch screen operations |
> 1,000,000 |
| Power supply |
24 V DC ± 15%. Less than 20 W. |
| Operating temperature |
0 ° to +50 °C |
| Storage temperature |
-10 ° to +60 °C |
| Relative operating humidity |
20 - 90% RH non-condensed |
| Vibration |
0.5 mm displacement, 10-55 Hz, 2 hours per X-, Y- and
Z-axis directions |
| Shock resistance |
10 G, 11 ms 3 times in each direction of X-, Y- and Z-axes |
| Cooling |
Natural cooling |
