供应5-40V 130W max UL/CE等 医
| 价 格： | 面议 |
品牌:sinpro 类型:医用开关电源适配器 型号:MPU100-102 输入电压:90-264（V） 输出功率:70（W） 输出电压:5（V） 工作效率:83（%） 输出纹波噪音:0.5% (Typ.) 电压调整率:5（%） 负载调整率:7（%） 产品认证:UL/c-UL, FCC, CB, TUV T-mark, PSE, CEC, Energy Star, RoHS
(The Ripple & Noise which is under 3.3VDC at 2% max)
3.Environmental
3.1 Operating Temperature: 0 to 70°C
3.2 Derate linearly from 100% load at 50°C to 50% load at 70°C
3.3 Storage Temperature: -40~85°C
3.4 Operating Humidity : 5~95%
3.5 Storage Humidity: 0~95%
3.6 MTBF: 100,000 calculated hours
4.Output Specification
4.1 Output Voltage:5~40VDC
4.2 Max. Output Current:2.50~14.00A
4.3 Max. Output Power:130W
4.4 Total Regulation:5%
4.5 Certificate:UL/c-UL, FCC, CB, TUV T-mark, PSE, CEC, Energy Star, RoHS
dzsc/18/2435/18243571.jpg
dzsc/18/2435/18243571.jpg
MPU series-Wall mount or Desktop type switching power supplies for Medical Equipment
The MPU series of AC/DC switching mode power supplies provide 10-130 watts of continuous output power. This series is suitable for use in Blood Pressure measurements, Frequency Therapy Device,Dental Curing light applications and many other hospital instruments.All models are designed to comply with UL/c-UL(UL60601-1),and new CE requirements.
1.Features
1.1 Wide Input Voltage 90 to 264 VAC, 47 to 63 Hz
1.2 IEC-320-C14 Input Inlet
1.3 Output Voltage Available from 5VDC through 40VDC
1.4 On/Off Switch (optional)
1.5 Single to Triple Output
1.6 Active Power Factor Correction
1.7 Class I
1.8 3 year warranty
2.Electrical characteristics
2.1 Efficiency: 83% typ.
2.2 Line Regulation: 1% max.
2.3 Load Regulation: 5% max.
2.4 Hold-up Time: 16mS Typ.
2.5 Output ripple and noise: 0.5% (Typ.).
dzsc/18/2435/18243571.jpg
dzsc/18/2435/18243571.jpg
