HONEYWELL 线性传感器 LF2S18N5K
| 价 格： | 面议 |
种类:传感器 品牌:HONEYWELL 型号:LF2S18N5KB6A
【现货供应】美国HONEYWELL线性传感器
产品型号：LF2S18N5KB6A
| Product Specifications | 技术参数： |
| Supply Voltage | 30 Vdc max. |
| Measurement Type | Linear |
| Housing Size | 538,2 mm [21.19 in] |
| Total Mechanical Travel | 459,8 mm [18.09 in] |
| Electrical Travel | 457,2 mm [18.0 in] |
| Starting Force (max.) | 0.45 kg max. [1.0 lb] |
| Linearity | ± 0.1 % |
| Backlash | 0,025 mm [.001 in] |
| Bearing Type | Sleeve |
| Shaft Material | Stainless Steel |
| Shaft Diameter | 1/4 in - 28 NF-2A thread |
| Type of Element | MystR® conductive plastic film |
| Housing Style | Anodized Aluminum |
| Termination | Binder Series 681 |
| Wiper Current | <1 μA |
| Resolution | Infinite |
| Operating Temperature Range | -65 °C to 105 °C [-85 °F to 221 °F] |
| Vibration | 20 g / 0,75 mm (rms) 5 hz to 2 khz |
| Shock | 50 g 11 ms half sine |
| Operating Life | one billion dither operations |
| Total Resistance | 5,000 Ohms |
| Resistance Tolerance | ± 20 % |
| Insulation Resistance | 1000 MOhm @ 500 Vdc |
| Dielectric Strength | 1000 V rms |
| Weight (Ranges) | 0.770 kg[1.7lb] |
| Sealing | NEMA 4 |
| UNSPSC Code | 41111945 |
| UNSPSC Commodity | 41111945 Linear position sensors |
| Availability | Global |
| Comments | Note;Mating Connector, Item Number 3718401,sold separately.Options;Electrical Tavel,Total Resistance,Linearity,Rod End Bearing,Ball Joint Assembly,Shaft Thread(M6 x 1Metric),Din 43650 Connector,Dual Elements |
| Series Name | LFII Series |
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 卢文锋
- 电话：0755-33654839
- 传真：0755-33654839
- 手机：
- QQ ：
HONEYWELL 线性传感器 MLT004N60
信息内容：种类:传感器 品牌:HONEYWELL 型号:MLT004N6000B5C【现货供应】美国HONEYWELL线性传感器 产品型号：MLT004N6000B5C Product Specifications技术参数：Supply Voltage30 Vdc max.Measurement TypeLinearHousing Size132,08 mm [5.2 in]Total Mechanical Travel102,87 mm [4.05 in]Electrical Travel101,6 mm [4.0 in]Starting Force (max.)28,35 g max. [1.0 oz max.]Linearity± 0.1 %Backlash0,0127 mm max. [0.0005 in max.]Bearing TypeSleeveShaft MaterialStainless SteelShaft Diameter1/8 in - #4-40 UNC-2A threadType of ElementMystR® conductive plastic filmHousing StyleAnodized AluminumTermination26 awg, 3 cond. - 305,0 mm [12.0in] cableWiper Current<1 μAResolutionInfiniteOperating Temperature Range-40 °C to 80 °C [-40 °F to 176 °F]Vibration20 g / 0,75 mm (rms) 5 hz to 2 khzShock50 g 11 ms half sineOperating Lifeone billion dither operationsTotal Resistance6,000 OhmsResistance Tolerance± 20 %Insulation Resistance500 MOhm @ 500 VdcDielectric Strength1000 V rmsWeight (Ranges)28...
HONEYWELL 线性传感器 F38000104
信息内容：种类:传感器 品牌:HONEYWELL 型号:F38000104【现货供应】美国HONEYWELL线性传感器（F38000104） Product Specifications技术参数：Supply Voltage30 Vdc max.Measurement TypeLinearHousing Size132,08 mm [5.2 in]Total Mechanical Travel102,87 mm [4.05 in]Electrical Travel101,6 mm [4.0 in]Starting Force (max.)28,35 g max. [1.0 oz max.]Linearity± 1.0 %Backlash0,0127 mm max. [0.0005 in max.]Bearing TypeSleeveShaft MaterialStainless SteelShaft Diameter1/8 in - #4-40 UNC-2A threadType of ElementMystR® conductive plastic filmHousing StyleAnodized AluminumTermination26 awg, 3 cond. - 305,0 mm [12.0in] cableWiper Current<1 μAResolutionInfiniteOperating Temperature Range-40 °C to 80 °C [-40 °F to 176 °F]Vibration20 g / 0,75 mm (rms) 5 hz to 2 khzShock50 g 11 ms half sineOperating Lifeone billion dither operationsTotal Resistance6,000 OhmsResistance Tolerance± 20 %Insulation Resistance500 MOhm @ 500 VdcDielectric Strength1000 V rmsWeight (Ranges)28 g [1.09 oz]Sealin...
