高质量三端稳压器，三极管78L05
| 价 格： | 8000.00 |
品牌:国产 型号:三极管 78L05 应用范围:功率 功率特性:小功率 频率特性:中频 结构:点接触型 材料:硅(Si) 封装形式:直插型 封装材料:塑料封装 营销方式:厂家直销 产品性质:热销
厂家直销，长期大量供应三极管78L05，欢迎来电咨询。dzsc/18/2277/18227720.jpg
ABSOLUTE MAXIMUM RATINGS (Operating trmperature applies unless otherwise specified)
Parameter | Symbol | Value | Units |
Input Voltage | VI | 30 | V |
Operating Junction Temperature Range | TOPR | 0～+125 | ℃ |
StorageTemperature Range | TSTG | -55～+150 | ℃ |
ELECTRICAL CHARACTERISTICS(V1=10V,o=40mA,Ci=0.33μF,Co=0.1μF,unless otherwise specified)
Parameter | Symbol | Test conditions | MIN | TYP | MAX | UNIT | |
Output voltage | Vo |
| 25℃ | 4.8 | 5.0 | 5.2 | v |
7V≤Vi≤20,IO=1mA40mA | 0-125℃ | 4.75 | 5.0 | 5.25 | V | ||
IO=1mA70mA | 4.75 | 5.0 | 5.25 | v | |||
Load Regulation | ΔVo | IO=1mA100mA | 25℃ |
| 15 | 60 | mV |
IO=1mA40mA | 25℃ |
| 8 | 30 | mV | ||
Line regulation | ΔVo | 7V≤ViI≤20 |
|
| 32 | 150 | mV |
8V≤Vi≤20 | 25℃ |
| 26 | 100 | mV | ||
Quiescent Current | Lq |
| 25℃ |
| 3.8 | 6 | mA |
Quiescent Current Change | Δlq | 8V≤Vi≤20 | 0-125℃ |
|
| 1.5 | mA |
Δlq | 1mA≤VI≤40mA | 0-125℃ |
|
| 0.1 | mA | |
Output Noise Voltage | VN | 10Hz≤f≤100KHz | 25℃ |
| 42 |
| uV |
Ripple Rejection | RR | 8V≤Vi≤20,f=120Hz | 0-125℃ | 41 | 49 |
| dB |
Dropout Voltage | Vd |
| 25℃ |
| 1.7 |
| V |
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 杨斌
- 电话：0755-29769280
- 传真：0755-29769280
- 手机：
- QQ ：
三极管S8050，C中，TO-92
信息内容：厂家直销，长期大量供应三极管S8050，ECB，TO-92，欢迎来电咨询。dzsc/18/8593/18859326.jpgELECTRICAL CHARACTERISTICS(Tamb=25℃unless otherwise specified) ParameterSymbolTest conditionsMINTYPMAXUNITCollector-base breakdown voltageV(BR)CBOlc=-100μA,lE=040 VCollector-emitter breakdown voltageV(BR)CEOlc=0.1 mA, lB=025 VEmitter-base breakdown voltageV(BR)EBOlE=-100μA,lc=05 VCollector cut-off currentlCBOVCB=-40V, lB=0 0.1μACollector cut-off currentlCEOVCE=-20V, lB=0 0.1μAEmitter cut-off currentlEBOVEB=-3V, lc=0 0.1μADC current gainhFE(1)VCE=-1V,lc=50mA160 300 Collector-emitter saturation voltageVCE(sat)lc=-800mA,lB=80mA 0.56VBase-emitter daturation voltageVBE(sat)lc=-500mA,lB=50mA 1.2VTransition frequencyfrVCE=-6V,lc=20mAf=30MHZ150 MHZ CLASSIFICATION OF hFE(1) RankBCDRange85-160120-200160-300
三极管S8050，EBC，TO-92
信息内容：厂家直销，长期大量供应三极管S8050，EBC，TO-92，欢迎来电咨询。 dzsc/18/8623/18862331.jpgELECTRICAL CHARACTERISTICS(Tamb=25℃unless otherwise specified) ParameterSymbolTest conditionsMINTYPMAXUNITCollector-base breakdown voltageV(BR)CBOlc=100μA, lE=040 VCollector-emitter breakdown voltageV(BR)CEOlc=0.1mA, lB=025 VEmitter-base breakdown voltageV(BR)EBOlE=100μA,lc=05 VCollector cut-off currentlCBOVCB=40V, lB=0 0.1μACollector cut-off currentlCEOVCE=20V, lB=0 1μAEmitter cut-off currentlEBOVEB=5V, lc=0 0.1μADC current gainhFEVCE=1V,lc=50mA85 400 Collector-emitter saturation voltageVCE(sat)lc=-500mA,lB=50mA 0. 6VBase-emitter saturation voltageVBE(sat)lc=-500mA,lB=50mA 1.2VTransition frequencyfTVCE=6V,lc=20mAf=30MHZ150180 MHZ CLASSIFICATION OF hFE(1)RankBCDD3Range85-160120-200160-300300-400
