LED升压板│LED恒流板│LED背光驱动板 LDA02-57V220C
| 价 格： | 面议 | |
| 型号/规格： | LDA02-57V220C | |
| 品牌/商标： | PACIT |
| 产品特性： | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 1. General description Scope: This LDA02-57V220C sepic LED driver for 23” of LCD backlight system. 2. Applications 23” LED Backlight LCD panels For LG LM215WF4-TLA1 LM215WF4-TLA3 3. Absolute maximum rating l Input supply voltage .: 11.0~13V l Input current . : 1.65A(MAX) l Input power : 18.17W l Output current : 130mA X 2CH l Output power : 15.99W l Brightness adjusted voltage : 0V(MAX)~5.0V(MIN) l Input signal voltage :0V/OFF 5.0V/ON ( l Ambient operating temperature : l Storage temperature : l Operating & storage humidify: 10%~85% l Over voltage protect(OVP) l High efficency (TYP:88% 4.Electrical Requirements 4.1Input Characteristics This section defines the electrical requirements for the LED driver
4.2 Output Characteristics: 4.2.1 DC output CN2:
5.0 Connector: 5.1 DC input connector
5.2 Output connector
|
- 所属城市：广东 珠海
- [联系时请说明来自维库仪器仪表网]
- 联系人： 杨小姐
- 电话：0756-3818829
- 传真：0756-3818826
- 手机：
- QQ ：
